Mitsubishi Electric BV-D

Mitsubishi Circuit breaker 2(1+N)

MPN
BV-D
Price and lead time confirmed within 1 business day
Request a Quote
  1. 1We check stock, condition and lead time
  2. 2You get a written quote by email
  3. 3Approve it and we ship — in-stock parts within 1 business day

A real person replies, typically within 1 business day — see our privacy policy.

  • 12-month warranty (new) · 3-month (used/refurbished)
  • 30-day returns, no restocking fee on unused parts
  • 100% positive eBay feedback
  • Ships via

Have spare Mitsubishi Electric (Factory Automation) parts? We buy surplus →

What is the Mitsubishi Electric BV-D?

The Mitsubishi Electric BV-D is a 2(1+N) in the Circuit breaker. IEC CE(EMC) CE(LVD) CE(RoHS) UKCA(EMC) UKCA(LV) UKCA(RoHS) CCC. Specifications and manuals below are Mitsubishi Electric's own data.

Specifications

Product

SeriesCircuit breaker
Category2(1+N)
OutlineIEC CE(EMC) CE(LVD) CE(RoHS) UKCA(EMC) UKCA(LV) UKCA(RoHS) CCC

Specifications

DescriptionRCCB
SeriesDIN series
TypeBV-D
Number of poles2(1+N)
Rated current In(A) at30℃25,40,63
Rated voltage (VAC)230
Rated current sensitivity I△n (mA)30,300
Max. operating time at 5I△n (s)0.04
Leakage detection characteristicsType AC
Rated conditional short-circuit current Inc (kA)6
Rated short-circuit capacity Icn(kA): IEC 61009-
Tripping characteristics-
Outline dimensions (mm): a36
Outline dimensions (mm): b85
Outline dimensions (mm): c44
Outline dimensions (mm): ca70
Mass (kg)0.2
Rated making and breaking capacity Im (A)500(In 25,40A) 630(In63A)
Rated residual making and breaking capacity I△m (A)500(In 25,40A) 630(In63A)
Rated conditional residual short-circuit current I△c (kA)6
Number of operating cycles (times): Without current8000
Number of operating cycles (times): With current8000
Type of overcurrent release-
MountingIEC35mm rail
Applicable wire size1-25mm2
Terminal connectionSolderless
Standard: Based onIEC 61008-1, IEC 61008-2-2, EN 61008-1, GB/T 16916.1, GB/T 16916.22
Standard: CE markingSelf-declaration
Standard: UKCA markingSelf-declaration
Standard: CCCCertified
Standard: Third party approval: KEMA-

BV-D: frequently asked questions

When can BV-D be shipped?

BV-D is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up BV-D in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for BV-D and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for BV-D, subject to availability and destination.
