Danfoss 1E16BF12

HOSE FTG, 1A/12, BF/16, CS, STR

MPN: 1E16BF12
Category: Spiral hose and fittings

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 1E16BF12?

Danfoss HOSE FTG, 1A/12, BF/16, CS, STR, manufacturer part number 1E16BF12. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

EAN/UPC	678146131645
A dimension IN	2.700
A dimension MM	68.700
Angle shape	Straight
Brand	Aeroquip by Danfoss
Compatible hose ID IN	0.750
Compatible hose ID MM	19.000
Compatible hoses	FC273, FC273B, FC500, GH810, FC254, GH506
Construction Style	Crimp
End size 1	-16
End type 1	Female BSPP swivel
Finish plating	Dura-Kote
Hex size 1 IN	1.614
Hex size 1 MM	40.996
Hose cut off factor IN	1.270
Hose cut off factor MM	32.300
Hose size	-12
Inside diameter IN	0.560
Inside diameter MM	14.200
Product height in	1.834
Product height mm	46.586
Product length in	3.220
Product length mm	81.788
Product material	Carbon steel
Product width in	1.834
Product width mm	46.583 mm
Seal material	Ethylene propylene (EPDM)
Series	1A/Z Series
Thread sealant	No
Thread size 1	G 1
Working pressure max BAR	280
Working pressure max PSI	4050
Working temperature max C	100
Working temperature max F	212
Working temperature min C	-40
Working temperature min F	-40
