Accessories for ball screw assemblies Parts
























Compare Accessories for ball screw assemblies
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Nominal size [mm] | Dynamic load capacity C [N] | Weight [kg] | Static load capacity C0 [N] | Dimension L3 [mm] |
|---|---|---|---|---|---|
| R159501720 | 25x5/10/25 | 18800.0 | 3.55 | 31000.0 | 17 |
| R159501220 | 20x5/10/20/40 | 17000.0 | 3.52 | 24700.0 | 15 |
| R159753000 | 40 | 29900.0 | 3.07 | 58500.0 | 12 |
| R159752500 | 40 | 29900.0 | 3.13 | 58500.0 | 12 |
| R159752000 | 32 | 25900.0 | 1.86 | 40500.0 | 10 |
| R159751700 | 25 | 25900.0 | 1.84 | 40500.0 | 10 |
| R159463000 | 40x5/10/12/16/20/25/30/40 | 19300.0 | 2.84 | 9800.0 | — |
| R159462000 | 32x5/10/20/32/64 | 12700.0 | 1.7 | 5700.0 | — |
| R159461500 | 20x5/10/20/40 | 7800.0 | 1.36 | 3250.0 | — |
| R159403000 | 40x5/10/12/16/20/25/30/40 | 29000.0 | 2.82 | 64000.0 | 20 |
| R159402000 | 32x5/10/20/32/64 | 26000.0 | 1.92 | 47000.0 | 18 |
| R159401200 | 20x5/10/20/40 | 17000.0 | 1.59 | 24700.0 | 15 |
| R159166020 | 80 x 10/20/40 | 52000.0 | 7.06 | 31000.0 | 145 |
| R159160620 | 12 x 2/5/10 | 2450.0 | 0.2 | 900.0 | 38 |
| R159165020 | 63 x 10/20/40 | 36500.0 | 5.3 | 20800.0 | 130 |
| R159160500 | 8 x 1/2/2,5/5 | 1900.0 | 0.16 | 590.0 | 38 |
| R159163520 | 50 x 10/12/16/20/25/30/40 | 25500.0 | 2.73 | 13200.0 | 92 |
| R159163510 | 50 x 5 | 25500.0 | 2.4 | 13200.0 | 92 |
| R159163020 | 40 x 5 | 19300.0 | 1.76 | 9800.0 | 80 |
| R159163010 | 40 x 10/12/16/20/25/30/40 | 19300.0 | 1.94 | 9800.0 | 80 |
| R159162020 | 32 x 5/10/20/32/64 | 12700.0 | 1.29 | 5700.0 | 70 |
| R159161720 | 25 x 5/10/25 | 9500.0 | 0.99 | 4150.0 | 66 |
| R159161220 | 20 x 5/10/20/40 | 6950.0 | 1 | 2650.0 | 60 |
| R159161020 | 16 x 5/10/16 | 6000.0 | 0.58 | 2240.0 | 52 |
