Linear sets with linear bushings Parts
Compare Linear sets with linear bushings
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Dynamic load capacity C [N] | Weight [kg] | Static load capacity C0 [N] | Dimension E1 [mm] | Dimension E2 [mm] |
|---|---|---|---|---|---|
| R103664020 | 10070.0 | 1.78 | 5570.0 | 86 | 58 |
| R103663020 | 5860.0 | 1 | 3570.0 | 68 | 45 |
| R103662520 | 4820.0 | 0.66 | 2790.0 | 60 | 40 |
| R103662020 | 2470.0 | 0.35 | 1340.0 | 45 | 32 |
| R103661620 | 1250.0 | 0.21 | 620.0 | 40 | 26 |
| R103661220 | 1020.0 | 0.13 | 490.0 | 32 | 23 |
| R103661020 | 730.0 | 0.11 | 380.0 | 29 | 20 |
| R109955079 | 15000.0 | 0 | 12940.0 | 194 | 100 |
| R109955089 | 15000.0 | 0 | 12940.0 | 194 | 100 |
| R109955085 | 15000.0 | 0.1 | 12940.0 | 194 | 100 |
| R109955080 | 15000.0 | 0.1 | 12940.0 | 194 | 100 |
| R109955088 | 15000.0 | 0.1 | 12940.0 | 194 | 100 |
| R109955087 | 15000.0 | 0.1 | 12940.0 | 194 | 100 |
| R109955069 | 15000.0 | 0 | 12940.0 | 194 | 100 |
| R109955086 | 15000.0 | 0 | 12940.0 | 194 | 100 |
| R109954079 | 10200.0 | 0 | 8700.0 | 148 | 80 |
| R109954089 | 10200.0 | 0 | 8700.0 | 148 | 80 |
| R109954085 | 10200.0 | 14.1 | 8700.0 | 148 | 80 |
| R109954080 | 10200.0 | 10 | 8700.0 | 148 | 80 |
| R109954088 | 10200.0 | 0.1 | 8700.0 | 148 | 80 |
| R109954087 | 10200.0 | 13 | 8700.0 | 148 | 80 |
| R109954069 | 10200.0 | 0 | 8700.0 | 148 | 80 |
| R109954086 | 10200.0 | 0 | 8700.0 | 148 | 80 |
| R109953079 | 6000.0 | 0 | 5580.0 | 130 | 62 |
Common to all listed parts
| Type | Linear set |
| Maximum acceleration rate amax [m/s²] | 150.0 |
| Maximum permissible linear speed vmax [m/s] | 3.0 |
| Permissible ambient temperature (min. ... max.) | -10 °C ... +80 °C |
