Siemens 6ES7223-3AD30-0XB0

Name: Siemens 6ES7223-3AD30-0XB0
Brand: Siemens
SKU: 6ES7223-3AD30-0XB0

MPN: 6ES7223-3AD30-0XB0 · Brand: Siemens

Price on request

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	SB 1223 digital input/output modules
Lifecycle	Active
Warranty	12-month (new) · 3-month (used/refurbished)
Weight	0.03 kg
Datasheet	Manufacturer datasheet ↗

Shipping & availability

When can 6ES7223-3AD30-0XB0 be shipped?

6ES7223-3AD30-0XB0 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 6ES7223-3AD30-0XB0 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 6ES7223-3AD30-0XB0 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 6ES7223-3AD30-0XB0, subject to availability and destination.

SIMATIC S7-1200, Digital I/O SB 1223, 2 DI/2 DQ, 5V DC 200kHz

Specifications

General information

Product type designation

SB 1223, DI 2x5 V DC/DQ 2x5 V DC 200 kHz

Input current

from backplane bus 5 V DC, typ.

35 mA

Power loss

Power loss, typ.

0.5 W

Digital inputs

Number of digital inputs	2; Current-sourcing
in groups of	2
Rated value (DC)	5 V
for signal "0"	(L+ minus 1.0 V DC) ... L+
for signal "1"	0 V ... (L+ minus 2.0 V DC)
for signal "0", max. (permissible quiescent current)	2.2 mA
for signal "1", min.	5.1 mA
for signal "1", typ.	15 mA
— parameterizable	Yes; 0.1 / 0.2 / 0.4 / 0.8 / 1.6 / 3.2 / 6.4 / 10.0 / 12.8 / 20.0 μs; 0.05 / 0.1 / 0.2 / 0.4 / 0.8 / 1.6 / 3.2 / 6.4 / 10.0 / 12.8 / 20.0 ms
— parameterizable	Yes
— parameterizable	Yes
shielded, max.	50 m; shielded, twisted pair

Digital outputs

Number of digital outputs	2; MOSFET, solid-state (current-sinking/current-sourcing)
in groups of	2
Short-circuit protection	No
with resistive load, max.	0.1 A
upper limit	7 Ω
Rated value (DC)	5 V
for signal "0", max.	0.2 V
for signal "1", min.	L+ minus 0.7 V DC
for signal "1", max.	6 V
for signal "1" rated value	0.1 A
for signal "1" permissible range, max.	0.1 A
shielded, max.	50 m

Interrupts/diagnostics/status information

for status of the inputs	Yes
for status of the outputs	Yes

Standards, approvals, certificates

CE mark	Yes
CSA approval	Yes
UL approval	Yes
cULus	Yes
FM approval	Yes
RCM (formerly C-TICK)	Yes
KC approval	Yes
Marine approval	Yes

Ambient conditions

Fall height, max.	0.3 m; five times, in product package
min.	-20 °C
max.	60 °C
horizontal installation, min.	-20 °C
horizontal installation, max.	60 °C
vertical installation, min.	-20 °C
vertical installation, max.	50 °C
min.	-40 °C
max.	70 °C
Storage/transport, min.	660 hPa
Storage/transport, max.	1 080 hPa
Operation at 25 ℃ without condensation, max.	95 %
