Schneider Electric TSXDSY08R4D – discrete output module Modicon Premium - 8 O relay
Discontinued by Schneider Electric — we can still source the original TSXDSY08R4D (new, used or refurbished, subject to availability). Request a quote below.
Request a Quote
Quick facts
| Availability | Confirmed on request |
| Category | Modicon Premium |
| Lifecycle | Discontinued |
| Warranty | 12-month (new) · 3-month (used/refurbished) |
| UPC / EAN | 3389110725797 |
| Recommended replacement | BMXDRA0804T |
| Datasheet | Manufacturer datasheet ↗ |
Shipping & availability
Can I still buy the TSXDSY08R4D now that it is discontinued?
Yes. Schneider Electric has discontinued the TSXDSY08R4D, but sourcing discontinued parts is what PartnerPLC specialises in — new old stock, used and refurbished units. Request a quote and we'll confirm availability, condition and lead time. If you are planning an upgrade instead, Schneider Electric names the BMXDRA0804T as its successor — we can quote both.
When can TSXDSY08R4D be shipped?
TSXDSY08R4D is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up TSXDSY08R4D in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for TSXDSY08R4D and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for TSXDSY08R4D, subject to availability and destination.
Schneider Electric TSXDSY08R4D — discrete output module Modicon Premium - 8 O relay. Discontinued by Schneider Electric; the manufacturer's successor is BMXDRA0804T. PartnerPLC sources discontinued and surplus Schneider Electric automation parts — request a quote for price, condition and lead time.
Specifications
Main
| Range of product | Modicon Premium Automation platform |
| Product or component type | Discrete output module |
| Discrete output number | 8 |
| Discrete output type | Relay protected |
| Discrete output voltage | 24...120 V DC conforming to EN/IEC 61131-2 19...143 V |
Complementary
| [Ith] conventional free air thermal current | 5 A |
| Response time | < 10 ms (activation); < 15 ms (deactivation) |
| Contacts type and composition | 2 x 2 C/O + 2 x 2 NO |
| Output overvoltage protection | RC circuit and Ge-Mov |
| Output overload protection | 6.3 A, interchangeable fuse per common fast blow |
| Short-circuit protection | 6.3 A, interchangeable fuse per common fast blow |
| isalotion resistance | > 10 MOhm 500 V |
| Power dissipation | (0.25 W + 0.24 W x No of outputs at state 1) |
| Electrical durability | 1000000 cycles DC-12 100 W 48 V resistive; 1000000 cycles DC-12 220 W 100...120 V resistive; 1000000 cycles DC-12 50 W 24 V resistive; 1000000 cycles DC-3 100 W 48 V inductive; 1000000 cycles DC-3 220 W 100...120 V inductive; 1000000 cycles DC-3 50 W 24 V inductive; 2000000 cycles DC-3 110 W 100...120 V inductive; 2000000 cycles DC-3 20 W 24 V inductive; 2000000 cycles DC-3 50 W 48 V inductive; 300000 cycles DC-12 100 W 24 V resistive; 300000 cycles DC-12 200 W 48 V resistive; 300000 cycles DC-12 440 W 100...120 V resistive |
| Marking | CE |
| Electrical connection | Screw terminal block |
| Current consumption | 55 mA at 5 V DC; 80 mA at 24 V DC rack |
| Module format | Standard |
| Net weight | 0.37 kg |
Environment
| Dielectric strength | 2000 V 50/60 Hz 60 s |
| Standards | 89/336/EEC; UL 508; CSA C22.2 No 213 Class I Division 2 Group C; 92/31/EEC; CSA C22.2 No 213 Class I Division 2 Group B; 73/23/EEC; CSA C22.2 No 213 Class I Division 2 Group D; CSA C22.2 No 142; 93/68/EEC; IEC 61131-2; CSA C22.2 No 213 Class I Division 2 Group A |
| Product certifications | LR; GL; DNV; RINA; BV; ABS; RMRS |
| Ambient air temperature for operation | 0…60 °C |
| Ambient air temperature for storage | -25…70 °C |
| Relative humidity | 10…95 % without condensation for operation; 5…95 % without condensation for storage |
| Operating altitude | 0...2000 m |
| Protective treatment | TC |
| IP degree of protection | IP20 |
| Pollution degree | 2 |
Downloads & documentation
Official documents from Schneider Electric, downloaded directly from the manufacturer.
Data sheets & manuals
| Product data sheet TSXDSY08R4D |
