Danfoss 1A10FR8

HOSE FTG, 1A/08, ORS-F/10, CS, STR

MPN: 1A10FR8
Category: Braided hose and fittings

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 1A10FR8?

Danfoss HOSE FTG, 1A/08, ORS-F/10, CS, STR, manufacturer part number 1A10FR8. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

EAN/UPC	678146168078
A dimension IN	2.510
A dimension MM	63.800
Angle shape	Straight
Brand	Aeroquip by Danfoss
Compatible hose ID IN	0.500
Compatible hose ID MM	12.700
Construction Style	Crimp
End connection torque	46-50 lb-ft(62-68 Nm)
End size 1	-10
End Type 1	Female ORFS swivel
Finish plating	Dura-Kote
Hex size 1 IN	1.180
Hex size 1 MM	29.972
Hex size 2 IN	0.875
Hex size 2 MM	22.000
Hose cut off factor IN	1.470
Hose cut off factor MM	37.300
Hose size	-8
Inside diameter IN	0.380
Inside diameter MM	9.600
Product height in	1.360
Product height mm	34.544
Product length in	3.130
Product length mm	79.502
Product material	Carbon steel
Product width in	1.180
Product width mm	29.972
Proposition 65	Cancer and Reproductive Harm
Series	1A/Z Series
Thread sealant	No
Thread size 1	1-14 UNS
Working pressure max BAR	552.00
Working pressure max PSI	8100.00
Working temperature max C	150
Working temperature max F	302
Working temperature min C	-40
Working temperature min F	-40
