B&R 5LS187.6

Communication module, 1x CAN bus

MPN: 5LS187.6

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via

What is the B&R 5LS187.6?

Logic scanner POWERLINK, PCI half-size module, 1 POWERLINK interface, managing or controlled node, 1 CAN interface, max. 500 kbps, object buffer in transmit and receive directions, network-capable, electrically isolated, 1 MB SRAM (Automation Runtime), order 2x TB704 terminal blocks separately!

Specifications

Short description

Communication module

1x CAN bus, 1x Ethernet POWERLINK managing or controlled node

General information

Diagnostics – Bus function (IF2)	Yes, using LED status indicator and software
Diagnostics – Data transfer (IF1)	Yes, using software
Diagnostics – Station status (IF2)	Yes, using LED status indicator and software
Electrical isolation – IF1 - IF2	Yes
Electrical isolation – PC - IFx	Yes
Certifications – CE	Yes
Certifications – UL	cULus E115267; Industrial control equipment
Ready relay	Normally open contact and normally closed contact, max. 30 VDC, max. 10 A
Status indicators	Status of the POWERLINK station, network activity, link/collision for IF2
Power consumption	4.0 W

Controller

SRAM	1 MB, battery-backed

Interfaces

Interface IF1 – Type	CAN bus
Interface IF1 – Variant	4-pin male multipoint connector
Interface IF1 – Max. transfer rate	500 kbit/s
Interface IF2 – Fieldbus	Ethernet POWERLINK
Interface IF2 – Type	100BASE-T (ANSI/IEEE 802.3)
Interface IF2 – Variant	Shielded RJ45 port
Interface IF2 – Line length	Max. 100 m between two stations (segment length)
Interface IF2 – Transfer rate	100 Mbit/s

Operating conditions

Degree of protection per EN 60529

IP20 in installed state

Ambient conditions

Temperature – Operation	0 to 55°C
Temperature – Storage	-25 to 70°C
Relative humidity – Operation	0 to 95%

Mechanical properties

Installation in – B&R Automation PC APC6xx	Yes
Installation in – B&R Panel PC	Yes
Installation in – Desktop PC	Yes
Note	Order 2x TB704 terminal blocks separately ; Lithium battery included in delivery
Slot	Standard PCI half-size module, plug and play

Accessories

Required accessories (order separately)

0TB704.91	Terminal blocks — The single-row 4-pin terminal block 0TB704 is used as the voltage supply terminal block and the connection terminal for fieldbuses.
0TB704.9	Terminal blocks — The single-row 4-pin terminal block 0TB704 is used as the voltage supply terminal block and the connection terminal for fieldbuses.

Optional accessories (3)

4A0006.00-000	Batteries — Lithium battery, 3 V / 950 mAh, button cell
0AC201.91	Batteries — Lithium batteries 4 pcs., 3 V / 950 mAh button cell
0AC913.93	Infrastructure components — Bus adapter, CAN bus, 2 CAN bus interfaces, including 03 m attachment cable (TB704)
