Bosch Rexroth 3842999715

BELT SECTION BS 2/K

MPN: 3842999715
Category: Belt section curves and rotary units

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Bosch Rexroth parts? We buy surplus →

What is the Bosch Rexroth 3842999715?

BS 2/K Belt Section

For driving a KE 2/O... curve

Conveyor medium: Toothed belt (suitable for use in an EPA)

Max. permissible section load up to 60 kg in accumulation operation (incl. the driven curve section)

Can be combined with WT 2, WT 2/F and WT 2/LS

Specifications

ESD	Yes
Length max [l max] [mm]	320
Length min [L min] [mm]	6000
Track width in direction of transport [b max] [mm]	1040
Track width in direction of transport [b min] [mm]	160
Section load in accumulation operation [kg]	60
Nominal speed [vN]	0 m/min ohne Motor und ohne Getriebe; 12 m/min; 15 m/min; 18 m/min; 6 m/min; 9 m/min
Track width in direction of transport [b min] 02 [mm]	320
Track width in direction of transport [b max] 02 [mm]	1040
Scope of delivery	Belt section, complete with drive motor
Delivery information	Motor included; Partially assembled
Preferred values [mm]	1040; 160; 240; 320; 400; 480; 640; 800
Conveyor medium	Toothed belt (suitable for use in an EPA)
Weight [kg]	0
