Beckhoff ER7342-0002
EtherCAT Box, 1-channel motion interface, DC motor, 48 V DC, 4.5 A, M12, with incremental encoder, zinc die-cast
- MPN
- ER7342-0002
Price and lead time confirmed within 1 business day
Request a Quote
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- Ships via
- 100% positive eBay feedback
What is the Beckhoff ER7342-0002?
The ER7342 EtherCAT Box enables direct operation of two DC motors. The speed or position is specified by the automation device via a 16 bit value. By connection of an incremental encoder (24 V DC, single-ended), a simple servo axis can be realized. The
Specifications
Specifications
| Protocol | EtherCAT |
| Bus interface | 2 x M8 socket, 4-pin, a-coded, shielded |
| Number of outputs | 2 |
| Connection method | M12 socket, 5-pin, a-coded |
| Rated load voltage | 8…48 V DC |
| Load type | DC brush motor, inductive |
| Output current | max. 2 x 3.5 A (short-circuit proof, common thermal overload warning for both output stages) per channel |
| Distributed clocks | yes |
| PWM clock frequency | 32 kHz with 180° phase shift each |
| Duty factor | 0…100% (voltage-controlled) |
| Resolution | max. 10 bit current, 16 bit speed |
| Power supply connection | feed: 1 x M8 male socket, 4-pin, a-coded; downstream connection: 1 x M8 female socket, 4-pin, a-coded |
| Electrical isolation | 500 V |
| Configuration | adaptation and optimisation of the respective motor via the controller |
| Current consumption sensor supply | 20 mA (see documentation) |
| Current consumption from US | 120 mA |
| Special features | travel distance control, encoder input |
| Weight | approx. 265 g |
| Operating temperature | -25…+60°C |
| Storage temperature | -40…+85°C |
| Vibration/shock resistance | conforms to EN 60068-2-6/EN 60068-2-27 |
| EMC immunity/emission | conforms to EN 61000-6-2/EN 61000-6-4 |
| Protect. rating/installation pos. | IP65/66/67 (conforms to EN 60529)/variable |
| Approvals/markings | CE |
| Dimensions (W x H x D) | 30 mm x 126 mm x 26.5 mm |
| Material | zinc die-cast |
| Installation | 2 fixing holes 3.5 mm diameter for M3 |
