Sensor-Actuator Cables Parts
Compare Sensor-Actuator Cables
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Order code (Pepperl+Fuchs part number) | Core construction | Length | Cable code | Mass |
|---|---|---|---|---|---|
| V31-GM-BK3M-PUR-A-V1-G | 314705 | 42 x 0.1 mm ∅ | 3 m L | Li F 9Y 11Y 4 x 0,34 | 93.57 g |
| V31-GM-BK2M-PUR-A-V1-G | 314704 | 42 x 0.1 mm ∅ | 2 m L | Li F 9Y 11Y 4 x 0,34 | 67.4 g |
| V31-GM-BK1M-PUR-A-V1-G | 314702 | 42 x 0.1 mm ∅ | 1 m L | Li F 9Y 11Y 4 x 0,34 | 40.6 g |
| V31-GM-BK0,6M-PUR-A-V1-G | 314701 | 42 x 0.1 mm ∅ | 0.6 m L | Li F 9Y 11Y 4 x 0,34 | 30.1 g |
| V31-GM-OR3M-POC-V1-G | 317171 | 19 x 0.16 mm ∅ | 3 m L | Li 7Y 41X 4 x 0,34 | 123.44 g |
| V31-GM-OR2M-POC-V1-G | 317169 | 19 x 0.16 mm ∅ | 2 m L | Li 7Y 41X 4 x 0,34 | 86.1 g |
| V31-GM-OR1,5M-POC-V1-G | 317168 | 19 x 0.16 mm ∅ | 1.5 m L | Li 7Y 41X 4 x 0,34 | 69.06 g |
| V1-W-BK10M-PUR-U-V1-W | 240777-100012 | 42 x 0.1 mm ∅ | 10 m L | Li 9Y 11Y 4 x 0.34 | 283.7 g |
| V1-W-BK2M-PUR-U-V1-W | 240777-100011 | 42 x 0.1 mm ∅ | 2 m L | Li 9Y 11Y 4 x 0.34 | 74 g |
| V1-W-BK3M-PVC-U-V1-W | 240777-100007 | 19 x 0.15 mm ∅ | 3 m L | Li YY 4 x 0,34 | 109.5 g |
| V31-GM-10M-PVC-V31-GM | 240813-100009 | 14 x 0.15 mm ∅ | 10 m L | Li YY 4 x 0,25 | 283.5 g |
| V1-W-BK0,6M-PUR-U-V1-W | 240777-100010 | 42 x 0.1 mm ∅ | 0.6 m L | Li 9Y 11Y 4 x 0.34 | 42 g |
| V1-W-BK5M-PVC-U-V1-W | 240777-100008 | 19 x 0.15 mm ∅ | 5 m L | Li YY 4 x 0,34 | 167.5 g |
| V1-W-OR2M-POC-V1-W | 240777-100014 | 19 x 0.16 mm ∅ | 2 m L | Li 7Y 41X 4 x 0,34 | 99 g |
| V1-W-OR10M-POC-V1-W | 240777-100017 | 19 x 0.16 mm ∅ | 10 m L | Li 7Y 41X 4 x 0,34 | 391 g |
| V1-W-A2-BK0,6M-PUR-A-V1-G | 240780-100014 | 42 x 0.1 mm ∅ | 0.6 m L | Li F 9Y 11Y 4 x 0,34 | 38.27 g |
| V1-W-0,6M-PUR-V31-GM | 243088 | 14 x 0.15 mm ∅ | 0.6 m L | Li 9Y 11Y 4 x 0,25 | 34.88 g |
| V1-W-0,1M-PUR-V1-G | 222806 | 19 x 0.15 mm ∅ | 0.1 m L | Li 9Y 11YM 4 x 0.34 | 21.5 g |
| V1-G-BK2,5M-PUR-A-V1-G | 240775-100032 | 42 x 0.1 mm ∅ | 2.5 m L | Li F 9Y 11Y 4 x 0,34 | 85 g |
| V1-G-BK3M-PUR-U-V1-W | 240778-100023 | 42 x 0.1 mm ∅ | 3 m L | Li 9Y 11Y 4 x 0.34 | 104 g |
| V1-G-BK1M-PUR-U-V1-W | 240778-100022 | 42 x 0.1 mm ∅ | 1 m L | Li 9Y 11Y 4 x 0.34 | 52 g |
| V1-G-BK5M-PUR-O1S-V1-W | 240790-100009 | 28 x 0.15 mm ∅ | 5 m L | Li 9Y C11Y 4 x 0,50 | 298 g |
| V1-G-BK2M-PUR-O1S-V1-W | 240790-100008 | 28 x 0.15 mm ∅ | 2 m L | Li 9Y C11Y 4 x 0,50 | 85.1 g |
| V1-G-BK3M-PVC-U-V1-W | 240778-100019 | 19 x 0.15 mm ∅ | 3 m L | Li YY 4 x 0,34 | 107.34 g |
Common to all listed parts
| Connector 1: Connection | socket |
| Connector 1: Locking | screw connection |
| Connector 1: Number of pins | 4 |
| Connector 1: Coding | A-coded |
| Connector 2: Connection | plug |
| Connector 2: Locking | screw connection |
| Connector 2: Number of pins | 4 |
| Connector 2: Coding | A-coded |
