3VA Molded Case Circuit Breakers up to 2000 A, UL / IEC Parts
Compare 3VA Molded Case Circuit Breakers up to 2000 A, UL / IEC
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | product designation / according to UL file | power loss [W] / maximum | power loss [W] / for rated value of the current / at AC / in hot operating state / per pole | Net Weight | adjustable response value setting current (Ii) / for I-tripping — minimum |
|---|---|---|---|---|---|
| 3VA6110-0KT41-0AA0 | EDAE | 13 W | 4.33 W | 2.821 kg | 150 A |
| 3VA5920-7EC31-1AA0 | CRAM | 658 W | 658 W | 3.133 kg | 5 000 A |
| 3VA5920-7EC31-0AA0 | CRAS | 658 W | 658 W | 24.4 kg | 5 000 A |
| 3VA5920-7BB31-0AA0 | CRAS | 658 W | 658 W | 24.4 kg | 12 000 A |
| 3VA5230-5ED36-0AA0 | MFAS | 18.5 W | 6.2 W | 2 100 g | 400 A |
| 3VA5230-5ED32-1AA0 | MFAM | 18.5 W | 6.2 W | 2 100 g | 400 A |
| 3VA5230-5ED32-0AA0 | MFAS | 18.5 W | 6.2 W | 2 100 g | 400 A |
| 3VA5225-7ED61-0AA0 | CFAS | 39 W | 19.33 W | 1.9 kg | 2 500 A |
| 3VA5225-7ED41-0AA0 | CFAS | 58 W | 19.33 W | 2.7 kg | 2 500 A |
| 3VA5225-7ED31-1AA0 | CFAM | 58 W | 19.33 W | 2 kg | 2 500 A |
| 3VA6560-6HM42-2AA0 | HMAE | 151 W | 50.33 W | 17.01 kg | 900 A |
| 3VA6560-6HM42-0AA0 | HMAE | 151 W | 50.33 W | 17.01 kg | 900 A |
| 3VA6560-6HM36-2AA0 | HMAE | 151 W | 50.33 W | 15.355 kg | 900 A |
| 3VA6560-6HM36-0AA0 | HMAE | 151 W | 50.33 W | 15.355 kg | 900 A |
| 3VA6560-6HM32-2AA0 | HMAE | 151 W | 50.33 W | 13.3 kg | 900 A |
| 3VA6560-6HM32-0AA0 | HMAE | 151 W | 50.33 W | 13.315 kg | 900 A |
| 3VA6560-6HL46-2AA0 | HMAE | 151 W | 50.33 W | 20.089 kg | 900 A |
| 3VA5220-5EC31-2AA0 | MFAS | 43 W | 14.2 W | 2 100 g | 1 000 A |
| 3VA5220-5EC31-1AA0 | MFAM | 43 W | 14.17 W | 2 kg | 1 000 A |
| 3VA5220-5EC31-0AA0 | MFAS | 43 W | 14.17 W | 2.028 kg | 1 000 A |
| 3VA5220-1MU31-0AA0 | CFAP | 34.8 W | 11.6 W | 2 kg | 600 A |
| 3VA5111-6ED31-1AA0 | HEAM | 25.8 W | 8.6 W | 0.88 kg | 1 100 A |
| 3VA5111-6ED31-0AA0 | HEAS | 25.8 W | 8.6 W | 950 g | 1 100 A |
| 3VA6110-5HL31-0AA0 | MDAE | 13 W | 4.33 W | 2.063 kg | 150 A |
Common to all listed parts
| product designation | Molded-case circuit breaker |
| design of the load switch / according to UL 489 / Heating, Air Conditioning, and Refrigeration circuit breaker (HACR Type) | Yes |
| product feature / for neutral conductors / upgradable/retrofittable / short-circuit and overload proof | No |
| product component — undervoltage release | No |
| product component — trip indicator | No |
| number of CO contacts / for auxiliary contacts | 0 |
| protection class IP / on the front | IP40 |
| ambient temperature — during operation / minimum | -25 °C |
