3VA Molded Case Circuit Breakers up to 2000 A, UL / IEC Parts
Compare 3VA Molded Case Circuit Breakers up to 2000 A, UL / IEC
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | product designation / according to UL file | power loss [W] / maximum | power loss [W] / for rated value of the current / at AC / in hot operating state / per pole | Net Weight | adjustable response value setting current (Ii) / for I-tripping — minimum |
|---|---|---|---|---|---|
| 3VA5712-5EC31-0AA0 | MNAS | 249 W | 249 W | 25 kg | 6 000 A |
| 3VA6160-0HN31-0AA0 | EDAE | 2.4 W | 0.8 W | 2.5 kg | 720 A |
| 3VA6160-0HM41-0AA0 | EDAE | 2.4 W | 0.8 W | 3.2 kg | 90 A |
| 3VA6210-6KP41-2AA0 | HFAE | 6.7 W | 2.23 W | 2.9 kg | 150 A |
| 3VA6115-7KT31-2AA0 | CDAE | 29 W | 9.67 W | 2.3 kg | 225 A |
| 3VA5217-6ED41-2AA0 | HFAS | 35 W | 11.7 W | 2 800 g | 1 750 A |
| 3VA5217-6ED41-0AA0 | HFAS | 35 W | 11.7 W | 2.7 kg | 1 750 A |
| 3VA5282-6ED36-1AA0 | HFAM | 9.1 W | 3 W | 2 100 g | 400 A |
| 3VA5282-6ED36-0AA0 | HFAS | 9.1 W | 3 W | 2 100 g | 400 A |
| 3VA5280-7ED31-2AA0 | CFAS | 20 W | 6.8 W | 2 100 g | 800 A |
| 3VA5280-7ED31-1AA0 | CFAM | 20 W | 6.8 W | 2 kg | 800 A |
| 3VA5280-7ED31-0AA0 | CFAS | 20 W | 6.8 W | 2 kg | 800 A |
| 3VA5280-7EC61-0AA0 | CFAS | 14 W | 6.8 W | 1.9 kg | 400 A |
| 3VA5280-7EC41-2AA0 | CFAS | 20 W | 6.8 W | 2 800 g | 400 A |
| 3VA5280-7EC41-0AA0 | CFAS | 20 W | 6.8 W | 2.7 kg | 400 A |
| 3VA6460-5HL41-0AA0 | MLAE | 151 W | 50.33 W | 6.9 kg | 900 A |
| 3VA5450-5GC41-0AA0 | MLAS | 122 W | 40.77 W | 6.82 kg | 2 500 A |
| 3VA5450-5EF41-0AA0 | MLAS | 122 W | 40.77 W | 6.82 kg | 2 500 A |
| 3VA5450-5EF31-0AA0 | MLAS | 122 W | 40.77 W | 4.761 kg | 2 500 A |
| 3VA5450-5EC61-0AA0 | MLAS | 82 W | 40.75 W | 4.95 kg | 2 500 A |
| 3VA5450-1MU31-0AA0 | CLAP | 120 W | 40 W | 5.2 kg | 1 500 A |
| 3VA5450-1MH31-0AA0 | CLAP | 120 W | 40 W | 5.2 kg | 4 000 A |
| 3VA5112-4ED31-1AA0 | SEAM | 30.1 W | 10.03 W | 970 g | 1 250 A |
| 3VA5112-4ED31-0AA0 | SEAS | 30.1 W | 10.03 W | 970 g | 1 250 A |
Common to all listed parts
| product designation | Molded-case circuit breaker |
| design of the load switch / according to UL 489 / Heating, Air Conditioning, and Refrigeration circuit breaker (HACR Type) | Yes |
| product component — undervoltage release | No |
| product component — trip indicator | No |
| number of CO contacts / for auxiliary contacts | 0 |
| protection class IP / on the front | IP40 |
| ambient temperature — during operation / minimum | -25 °C |
| ambient temperature — during operation / maximum | 70 °C |
