Linear bushings Parts
























Compare Linear bushings
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Shaft diameter d [mm] | Dynamic load capacity C [N] | Dynamic torsional moment load capacity Mt [Nm] | Length of linear bushing [mm] | Weight [kg] |
|---|---|---|---|---|---|
| R069604000 | 40.0 | 6320.0 | 53.0 | 80.0 | 0.43 |
| R069603079 | 30.0 | 3680.0 | 23.0 | 68.0 | 0 |
| R069603089 | 30.0 | 3680.0 | 23.0 | 68.0 | 0 |
| R069603085 | 30.0 | 3680.0 | 23.0 | 68.0 | 0.1 |
| R069603080 | 30.0 | 3680.0 | 23.0 | 68.0 | 3.57 |
| R069603088 | 30.0 | 3680.0 | 23.0 | 68.0 | 12.5 |
| R069603087 | 30.0 | 3680.0 | 23.0 | 68.0 | 0.1 |
| R069603069 | 30.0 | 3680.0 | 23.0 | 68.0 | 0 |
| R069603086 | 30.0 | 3680.0 | 23.0 | 68.0 | 0 |
| R069603000 | 30.0 | 3680.0 | 23.0 | 68.0 | 0.25 |
| R069602579 | 25.0 | 3030.0 | 15.0 | 58.0 | 0 |
| R069602589 | 25.0 | 3030.0 | 15.0 | 58.0 | 0 |
| R069602585 | 25.0 | 3030.0 | 15.0 | 58.0 | 4.27 |
| R069602580 | 25.0 | 3030.0 | 15.0 | 58.0 | 2.08 |
| R069602588 | 25.0 | 3030.0 | 15.0 | 58.0 | 0.1 |
| R069602587 | 25.0 | 3030.0 | 15.0 | 58.0 | 4.78 |
| R069602569 | 25.0 | 3030.0 | 15.0 | 58.0 | 0 |
| R069602586 | 25.0 | 3030.0 | 15.0 | 58.0 | 0 |
| R069602500 | 25.0 | 3030.0 | 15.0 | 58.0 | 0.16 |
| R069602079 | 20.0 | 1550.0 | 7.5 | 45.0 | 0 |
| R069602089 | 20.0 | 1550.0 | 7.5 | 45.0 | 0 |
| R069602085 | 20.0 | 1550.0 | 7.5 | 45.0 | 2.25 |
| R069602080 | 20.0 | 1550.0 | 7.5 | 45.0 | 1.33 |
| R069602088 | 20.0 | 1550.0 | 7.5 | 45.0 | 6.25 |
Common to all listed parts
| Version | Standard |
| Format of linear bushings | – Closed |
| Series | Torque |
| Type | Linear bushing |
| Seal | Without wiper seals |
| Raceway grooves | 1 |
| Maximum acceleration rate amax [m/s²] | 150.0 |
| Maximum permissible linear speed vmax [m/s] | 3.0 |
