Linear bushings Parts
























Compare Linear bushings
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Shaft diameter d [mm] | Dynamic load capacity C [N] | Dynamic torsional moment load capacity Mt [Nm] | Length of linear bushing [mm] | Weight [kg] |
|---|---|---|---|---|---|
| R069634088 | 40.0 | 6320.0 | 86.0 | 80.0 | 20 |
| R069634087 | 40.0 | 6320.0 | 86.0 | 80.0 | 17 |
| R069634069 | 40.0 | 6320.0 | 86.0 | 80.0 | 0 |
| R069634086 | 40.0 | 6320.0 | 86.0 | 80.0 | 0 |
| R069634000 | 40.0 | 6320.0 | 86.0 | 80.0 | 0.47 |
| R069633079 | 30.0 | 3680.0 | 37.0 | 68.0 | 0 |
| R069633089 | 30.0 | 3680.0 | 37.0 | 68.0 | 0 |
| R069633085 | 30.0 | 3680.0 | 37.0 | 68.0 | 5.94 |
| R069633080 | 30.0 | 3680.0 | 37.0 | 68.0 | 3.7 |
| R069633088 | 30.0 | 3680.0 | 37.0 | 68.0 | 11.21 |
| R069633087 | 30.0 | 3680.0 | 37.0 | 68.0 | 6.94 |
| R069633069 | 30.0 | 3680.0 | 37.0 | 68.0 | 0 |
| R069633086 | 30.0 | 3680.0 | 37.0 | 68.0 | 0 |
| R069633000 | 30.0 | 3680.0 | 37.0 | 68.0 | 0.29 |
| R069632579 | 25.0 | 3030.0 | 24.0 | 58.0 | 0 |
| R069632589 | 25.0 | 3030.0 | 24.0 | 58.0 | 0 |
| R069632585 | 25.0 | 3030.0 | 24.0 | 58.0 | 3.64 |
| R069632580 | 25.0 | 3030.0 | 24.0 | 58.0 | 2.35 |
| R069632588 | 25.0 | 3030.0 | 24.0 | 58.0 | 0.08 |
| R069632587 | 25.0 | 3030.0 | 24.0 | 58.0 | 0.1 |
| R069632569 | 25.0 | 3030.0 | 24.0 | 58.0 | 0 |
| R069632586 | 25.0 | 3030.0 | 24.0 | 58.0 | 0 |
| R069632500 | 25.0 | 3030.0 | 24.0 | 58.0 | 0.19 |
| R069632079 | 20.0 | 1550.0 | 12.0 | 45.0 | 0 |
Common to all listed parts
| Version | Standard |
| Format of linear bushings | – Closed |
| Series | Torque |
| Type | Linear bushing |
| Seal | Without wiper seals |
| Raceway grooves | 2 |
| Maximum acceleration rate amax [m/s²] | 150.0 |
| Maximum permissible linear speed vmax [m/s] | 3.0 |
