Linear bushings Parts
























Compare Linear bushings
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Shaft diameter d [mm] | Dynamic load capacity C [N] | Length of linear bushing [mm] | Weight [kg] | Breakaway force [N] |
|---|---|---|---|---|---|
| R073123045 | 30.0 | 6300.0 | 68.0 | 0.25 | 13.5 |
| R073123040 | 30.0 | 6300.0 | 68.0 | 0.25 | 9 |
| R073113040 | 30.0 | 6300.0 | 68.0 | 0.04 | 9 |
| R073103000 | 30.0 | 6300.0 | 68.0 | 0.25 | 9 |
| R073122545 | 25.0 | 6190.0 | 58.0 | 0.16 | 10.5 |
| R073122540 | 25.0 | 6190.0 | 58.0 | 0.16 | 7 |
| R073112540 | 25.0 | 6190.0 | 58.0 | 0.16 | 7 |
| R073102500 | 25.0 | 6190.0 | 58.0 | 0.16 | 7 |
| R073122045 | 20.0 | 3530.0 | 45.0 | 0.08 | 7.5 |
| R073122040 | 20.0 | 3530.0 | 45.0 | 0.08 | 5 |
| R073112040 | 20.0 | 3530.0 | 45.0 | 0.08 | 5 |
| R073102000 | 20.0 | 3530.0 | 45.0 | 0.08 | 5 |
| R073025040 | 50.0 | 22300.0 | 100.0 | 1.03 | 15 |
| R073015040 | 50.0 | 22300.0 | 100.0 | 1.03 | 15 |
| R073005000 | 50.0 | 22300.0 | 100.0 | 1.03 | 15 |
| R073024040 | 40.0 | 13500.0 | 80.0 | 0.6 | 12 |
| R073014040 | 40.0 | 13500.0 | 80.0 | 0.6 | 12 |
| R073004000 | 40.0 | 13500.0 | 80.0 | 0.59 | 12 |
| R073023040 | 30.0 | 6300.0 | 68.0 | 0.3 | 9 |
| R073013040 | 30.0 | 6300.0 | 68.0 | 0.3 | 9 |
| R073003000 | 30.0 | 6300.0 | 68.0 | 0.3 | 9 |
| R073022540 | 25.0 | 6190.0 | 58.0 | 0.19 | 7 |
| R073012540 | 25.0 | 6190.0 | 58.0 | 0.19 | 7 |
| R073002500 | 25.0 | 6190.0 | 58.0 | 0.19 | 7 |
Common to all listed parts
| Version | Standard |
| Series | Super SH |
| Type | Linear bushing |
| Lubrication | Not lubricated |
| Note: dynamic load capacity C | The load capacities apply for the main direction of loading. |
| Maximum acceleration rate amax [m/s²] | 150.0 |
| Maximum permissible linear speed vmax [m/s] | 5.0 |
| Permissible ambient temperature (min. ... max.) | -20 °C ... +80 °C |
