Linear bushings Parts
























Compare Linear bushings
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Shaft diameter d [mm] | Dynamic load capacity C [N] | Dynamic torsional moment load capacity Mt [Nm] | Length of linear bushing [mm] | Weight [kg] |
|---|---|---|---|---|---|
| R069632089 | 20.0 | 1550.0 | 12.0 | 45.0 | 0 |
| R069632085 | 20.0 | 1550.0 | 12.0 | 45.0 | 3.04 |
| R069632080 | 20.0 | 1550.0 | 12.0 | 45.0 | 1.35 |
| R069632088 | 20.0 | 1550.0 | 12.0 | 45.0 | 4.96 |
| R069632087 | 20.0 | 1550.0 | 12.0 | 45.0 | 3.1 |
| R069632086 | 20.0 | 1550.0 | 12.0 | 45.0 | 0 |
| R069632000 | 20.0 | 1550.0 | 12.0 | 45.0 | 0.13 |
| R069605079 | 50.0 | 9250.0 | 103.0 | 100.0 | 0 |
| R069605089 | 50.0 | 9250.0 | 103.0 | 100.0 | 0 |
| R069605085 | 50.0 | 9250.0 | 103.0 | 100.0 | 14 |
| R069605080 | 50.0 | 9250.0 | 103.0 | 100.0 | 0.1 |
| R069605088 | 50.0 | 9250.0 | 103.0 | 100.0 | 31.3 |
| R069605087 | 50.0 | 9250.0 | 103.0 | 100.0 | 0.1 |
| R069605069 | 50.0 | 9250.0 | 103.0 | 100.0 | 0 |
| R069605086 | 50.0 | 9250.0 | 103.0 | 100.0 | 0 |
| R069605000 | 50.0 | 9250.0 | 103.0 | 100.0 | 0.73 |
| R069604079 | 40.0 | 6320.0 | 53.0 | 80.0 | 0 |
| R069604089 | 40.0 | 6320.0 | 53.0 | 80.0 | 0 |
| R069604085 | 40.0 | 6320.0 | 53.0 | 80.0 | 9.95 |
| R069604080 | 40.0 | 6320.0 | 53.0 | 80.0 | 7.18 |
| R069604088 | 40.0 | 6320.0 | 53.0 | 80.0 | 10.19 |
| R069604087 | 40.0 | 6320.0 | 53.0 | 80.0 | 12.28 |
| R069604069 | 40.0 | 6320.0 | 53.0 | 80.0 | 0 |
| R069604086 | 40.0 | 6320.0 | 53.0 | 80.0 | 0 |
Common to all listed parts
| Version | Standard |
| Format of linear bushings | – Closed |
| Series | Torque |
| Type | Linear bushing |
| Seal | Without wiper seals |
| Maximum acceleration rate amax [m/s²] | 150.0 |
| Maximum permissible linear speed vmax [m/s] | 3.0 |
| Permissible ambient temperature (min. ... max.) | -10 °C ... +80 °C |
