Linear bushings Parts
























Compare Linear bushings
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Shaft diameter d [mm] | Maximum dynamic load capacity Cmax [N] | Length of linear bushing [mm] | Outer diameter D [mm] | Weight [kg] |
|---|---|---|---|---|---|
| R060006000 | 60.0 | 12100.0 | 125.0 | 90.0 | 2.02 |
| R060205010 | 50.0 | 8740.0 | 100.0 | 75.0 | 1.03 |
| R060105010 | 50.0 | 8740.0 | 100.0 | 75.0 | 1.06 |
| R060005000 | 50.0 | 8740.0 | 100.0 | 75.0 | 1.09 |
| R060000530 | 5.0 | 185.0 | 22.0 | 12.0 | 0.02 |
| R060200530 | 5.0 | 185.0 | 22.0 | 12.0 | 0.02 |
| R060230510 | 5.0 | 210.0 | 22.0 | 12.0 | 0.01 |
| R060130510 | 5.0 | 210.0 | 22.0 | 12.0 | 0.01 |
| R060030500 | 5.0 | 210.0 | 22.0 | 12.0 | 0.02 |
| R060004030 | 40.0 | 1820.0 | 80.0 | 62.0 | 0.73 |
| R060204030 | 40.0 | 1820.0 | 80.0 | 62.0 | 0.73 |
| R060204010 | 40.0 | 5480.0 | 80.0 | 62.0 | 0.52 |
| R060104010 | 40.0 | 5480.0 | 80.0 | 62.0 | 0.61 |
| R060004000 | 40.0 | 5480.0 | 80.0 | 62.0 | 0.62 |
| R060000430 | 4.0 | 80.0 | 12.0 | 8.0 | 0.01 |
| R060030400 | 4.0 | 80.0 | 12.0 | 8.0 | 0.01 |
| R060003030 | 30.0 | 1320.0 | 68.0 | 47.0 | 0.36 |
| R060203030 | 30.0 | 1320.0 | 68.0 | 47.0 | 0.35 |
| R060203010 | 30.0 | 2980.0 | 68.0 | 47.0 | 0.31 |
| R060103010 | 30.0 | 2980.0 | 68.0 | 47.0 | 0.31 |
| R060003000 | 30.0 | 2980.0 | 68.0 | 47.0 | 0.31 |
| R060000330 | 3.0 | 65.0 | 10.0 | 7.0 | 0.01 |
| R060030300 | 3.0 | 65.0 | 10.0 | 7.0 | 0.01 |
| R060002530 | 25.0 | 830.0 | 58.0 | 40.0 | 0.24 |
Common to all listed parts
| Format of linear bushings | – Closed |
| Series | Standard (metal) |
| Type | Linear bushing |
| Lubrication | Not lubricated |
| Permissible ambient temperature (min. ... max.) | -10 °C ... +80 °C |
| Friction coefficient μ | 0.001 ... 0.004 |
| Footnote breakaway force | One wiper seal: Multiply value with factor 0.5 |
| Footnote friction force FR | One wiper seal: Multiply value with factor 0.5 |
