Linear bushings Parts
























Compare Linear bushings
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Shaft diameter d [mm] | Length of linear bushing [mm] | Outer diameter D [mm] | Weight [kg] | Breakaway force [N] |
|---|---|---|---|---|---|
| R063101600 | 16.0 | 36.0 | 26.0 | 0.04 | 12 |
| R063001600 | 16.0 | 36.0 | 26.0 | 0.05 | 12 |
| R063201200 | 12.0 | 32.0 | 22.0 | 0.04 | 8 |
| R063101200 | 12.0 | 32.0 | 22.0 | 0.04 | 8 |
| R063001200 | 12.0 | 32.0 | 22.0 | 0.04 | 8 |
| R061208010 | 80.0 | 165.0 | 120.0 | 4.54 | 45 |
| R061108010 | 80.0 | 165.0 | 120.0 | 4.6 | 45 |
| R061008000 | 80.0 | 165.0 | 120.0 | 4.71 | 45 |
| R061230810 | 8.0 | 25.0 | 16.0 | 0.02 | 1 |
| R061130810 | 8.0 | 25.0 | 16.0 | 0.03 | 1 |
| R061030800 | 8.0 | 25.0 | 16.0 | 0.02 | 1 |
| R061206010 | 60.0 | 125.0 | 90.0 | 1.93 | 36 |
| R061106010 | 60.0 | 125.0 | 90.0 | 1.97 | 36 |
| R061006000 | 60.0 | 125.0 | 90.0 | 2.01 | 36 |
| R061205010 | 50.0 | 100.0 | 75.0 | 1.03 | 30 |
| R061105010 | 50.0 | 100.0 | 75.0 | 1.06 | 30 |
| R061005000 | 50.0 | 100.0 | 75.0 | 1.09 | 30 |
| R061230510 | 5.0 | 22.0 | 12.0 | 0.02 | 0.8 |
| R061130510 | 5.0 | 22.0 | 12.0 | 0.02 | 0.8 |
| R061030500 | 5.0 | 22.0 | 12.0 | 0.02 | 0.8 |
| R061204010 | 40.0 | 80.0 | 62.0 | 0.59 | 24 |
| R061104010 | 40.0 | 80.0 | 62.0 | 0.6 | 24 |
| R061004000 | 40.0 | 80.0 | 62.0 | 0.62 | 24 |
| R061203010 | 30.0 | 68.0 | 47.0 | 0.3 | 18 |
Common to all listed parts
| Version | Standard |
| Series | Standard (metal) |
| Type | Linear bushing |
| Lubrication | Not lubricated |
| Permissible ambient temperature (min. ... max.) | -10 °C ... +80 °C |
| Friction coefficient μ | 0.001 ... 0.004 |
| Footnote breakaway force | One wiper seal: Multiply value with factor 0.5 |
| Footnote friction force FR | One wiper seal: Multiply value with factor 0.5 |
