Linear bushings Parts
























Compare Linear bushings
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Shaft diameter d [mm] | Length of linear bushing [mm] | Outer diameter D [mm] | Weight [kg] | Breakaway force [N] |
|---|---|---|---|---|---|
| R067101600 | 16.0 | 36.0 | 26.0 | 0.04 | 2 |
| R067121245 | 12.0 | 32.0 | 22.0 | 0.03 | 6 |
| R067121240 | 12.0 | 32.0 | 22.0 | 0.03 | 1.5 |
| R067111240 | 12.0 | 32.0 | 22.0 | 0.03 | 1.5 |
| R067101200 | 12.0 | 32.0 | 22.0 | 0.03 | 1.5 |
| R067025040 | 50.0 | 100.0 | 75.0 | 0.62 | 10 |
| R067015040 | 50.0 | 100.0 | 75.0 | 0.62 | 10 |
| R067005000 | 50.0 | 100.0 | 75.0 | 0.63 | 10 |
| R067024040 | 40.0 | 80.0 | 62.0 | 0.38 | 8 |
| R067014040 | 40.0 | 80.0 | 62.0 | 0.38 | 8 |
| R067004000 | 40.0 | 80.0 | 62.0 | 0.38 | 8 |
| R067023040 | 30.0 | 68.0 | 47.0 | 0.2 | 6 |
| R067013040 | 30.0 | 68.0 | 47.0 | 0.2 | 6 |
| R067003000 | 30.0 | 68.0 | 47.0 | 0.2 | 6 |
| R067022540 | 25.0 | 58.0 | 40.0 | 0.14 | 4.5 |
| R067012540 | 25.0 | 58.0 | 40.0 | 0.14 | 4.5 |
| R067002500 | 25.0 | 58.0 | 40.0 | 0.14 | 4.5 |
| R067022040 | 20.0 | 45.0 | 32.0 | 0.07 | 3 |
| R067012040 | 20.0 | 45.0 | 32.0 | 0.07 | 3 |
| R067002000 | 20.0 | 45.0 | 32.0 | 0.07 | 3 |
| R067021640 | 16.0 | 36.0 | 26.0 | 0.04 | 2 |
| R067011640 | 16.0 | 36.0 | 26.0 | 0.04 | 2 |
| R067001600 | 16.0 | 36.0 | 26.0 | 0.04 | 2 |
| R067021240 | 12.0 | 32.0 | 22.0 | 0.03 | 1.5 |
Common to all listed parts
| Version | Standard |
| Series | Super A (with self-alignment feature) |
| Type | Linear bushing |
| Lubrication | Not lubricated |
| Maximum acceleration rate amax [m/s²] | 150.0 |
| Maximum permissible linear speed vmax [m/s] | 3.0 |
| Permissible ambient temperature (min. ... max.) | -10 °C ... +80 °C |
| Friction coefficient μ | 0.001 ... 0.0025 |
