Linear bushings Parts
























Compare Linear bushings
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Shaft diameter d [mm] | Length of linear bushing [mm] | Outer diameter D [mm] | Weight [kg] | Breakaway force [N] |
|---|---|---|---|---|---|
| R067301200 | 12.0 | 32.0 | 22.0 | 0.03 | 1.5 |
| R067225040 | 50.0 | 100.0 | 75.0 | 0.63 | 10 |
| R067215040 | 50.0 | 100.0 | 75.0 | 0.62 | 10 |
| R067205000 | 50.0 | 100.0 | 75.0 | 0.63 | 10 |
| R067224040 | 40.0 | 80.0 | 62.0 | 0.38 | 8 |
| R067214040 | 40.0 | 80.0 | 62.0 | 0.38 | 8 |
| R067204000 | 40.0 | 80.0 | 62.0 | 0.38 | 8 |
| R067223040 | 30.0 | 68.0 | 47.0 | 0.2 | 6 |
| R067213040 | 30.0 | 68.0 | 47.0 | 0.2 | 6 |
| R067203000 | 30.0 | 68.0 | 47.0 | 0.2 | 6 |
| R067222540 | 25.0 | 58.0 | 40.0 | 0.14 | 4.5 |
| R067212540 | 25.0 | 58.0 | 40.0 | 0.14 | 4.5 |
| R067202500 | 25.0 | 58.0 | 40.0 | 0.14 | 4.5 |
| R067222040 | 20.0 | 45.0 | 32.0 | 0.07 | 3 |
| R067212040 | 20.0 | 45.0 | 32.0 | 0.07 | 3 |
| R067202000 | 20.0 | 45.0 | 32.0 | 0.07 | 3 |
| R067221640 | 16.0 | 36.0 | 26.0 | 0.04 | 2 |
| R067211640 | 16.0 | 36.0 | 26.0 | 0.04 | 2 |
| R067201600 | 16.0 | 36.0 | 26.0 | 0.04 | 2 |
| R067221240 | 12.0 | 32.0 | 22.0 | 0.02 | 1.5 |
| R067211240 | 12.0 | 32.0 | 22.0 | 0.03 | 1.5 |
| R067201200 | 12.0 | 32.0 | 22.0 | 0.03 | 1.5 |
| R067221040 | 10.0 | 29.0 | 19.0 | 0.02 | 1 |
| R067211040 | 10.0 | 29.0 | 19.0 | 0.02 | 1 |
Common to all listed parts
| Version | Standard |
| Series | Super B (no self-alignment feature) |
| Type | Linear bushing |
| Lubrication | Not lubricated |
| Maximum acceleration rate amax [m/s²] | 150.0 |
| Maximum permissible linear speed vmax [m/s] | 3.0 |
| Permissible ambient temperature (min. ... max.) | -10 °C ... +80 °C |
| Friction coefficient μ | 0.001 ... 0.0025 |
