Linear bushings Parts
























Compare Linear bushings
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Shaft diameter d [mm] | Dynamic load capacity C [N] | Length of linear bushing [mm] | Weight [kg] | Breakaway force [N] |
|---|---|---|---|---|---|
| R067305000 | 50.0 | 12500.0 | 100.0 | 0.56 | 10 |
| R067324045 | 40.0 | 8620.0 | 80.0 | 0.33 | 24 |
| R067324040 | 40.0 | 8620.0 | 80.0 | 0.33 | 8 |
| R067314040 | 40.0 | 8620.0 | 80.0 | 0.33 | 8 |
| R067304000 | 40.0 | 8620.0 | 80.0 | 0.33 | 8 |
| R067323045 | 30.0 | 5020.0 | 68.0 | 0.18 | 18 |
| R067323040 | 30.0 | 5020.0 | 68.0 | 0.18 | 6 |
| R067313040 | 30.0 | 5020.0 | 68.0 | 0.18 | 6 |
| R067303000 | 30.0 | 5020.0 | 68.0 | 0.18 | 6 |
| R067322545 | 25.0 | 4130.0 | 58.0 | 0.12 | 14 |
| R067322540 | 25.0 | 4130.0 | 58.0 | 0.12 | 4.5 |
| R067312540 | 25.0 | 4130.0 | 58.0 | 0.12 | 4.5 |
| R067302500 | 25.0 | 4130.0 | 58.0 | 0.12 | 4.5 |
| R067322045 | 20.0 | 2570.0 | 45.0 | 0.07 | 10 |
| R067322040 | 20.0 | 2570.0 | 45.0 | 0.07 | 3 |
| R067312040 | 20.0 | 2570.0 | 45.0 | 0.06 | 3 |
| R067302000 | 20.0 | 2570.0 | 45.0 | 0.06 | 3 |
| R067321645 | 16.0 | 1500.0 | 36.0 | 0.04 | 9 |
| R067321640 | 16.0 | 1500.0 | 36.0 | 0.04 | 2 |
| R067311640 | 16.0 | 1500.0 | 36.0 | 0.04 | 2 |
| R067301600 | 16.0 | 1500.0 | 36.0 | 0.03 | 2 |
| R067321245 | 12.0 | 1060.0 | 32.0 | 0.03 | 6 |
| R067321240 | 12.0 | 1060.0 | 32.0 | 0.03 | 1.5 |
| R067311240 | 12.0 | 1060.0 | 32.0 | 0.03 | 1.5 |
Common to all listed parts
| Version | Standard |
| Format of linear bushings | O - Open |
| Series | Super B (no self-alignment feature) |
| Type | Linear bushing |
| Lubrication | Not lubricated |
| Note: dynamic load capacity C | The load capacities apply for the main direction of loading. |
| Maximum acceleration rate amax [m/s²] | 150.0 |
| Maximum permissible linear speed vmax [m/s] | 3.0 |
