Linear bushings Parts
























Compare Linear bushings
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | Shaft diameter d [mm] | Dynamic load capacity C [N] | Weight [kg] | Static load capacity C0 [N] | Breakaway force [N] |
|---|---|---|---|---|---|
| R073022040 | 20.0 | 3530.0 | 0.1 | 2530.0 | 5 |
| R073012040 | 20.0 | 3530.0 | 0.1 | 2530.0 | 5 |
| R073002000 | 20.0 | 3530.0 | 0.1 | 2530.0 | 5 |
| R073326045 | 60.0 | 23500.0 | 1.03 | 18700.0 | 27 |
| R073326040 | 60.0 | 23500.0 | 1.03 | 18700.0 | 18 |
| R073316040 | 60.0 | 23500.0 | 0.1 | 18700.0 | 18 |
| R073306000 | 60.0 | 23500.0 | 1.02 | 18700.0 | 18 |
| R073325045 | 50.0 | 16000.0 | 0.6 | 12200.0 | 22.5 |
| R073325040 | 50.0 | 16000.0 | 0.6 | 12200.0 | 15 |
| R073315040 | 50.0 | 16000.0 | 0.6 | 12200.0 | 15 |
| R073305000 | 50.0 | 16000.0 | 0.6 | 12200.0 | 15 |
| R073324045 | 40.0 | 9680.0 | 0.36 | 7600.0 | 18 |
| R073324040 | 40.0 | 9680.0 | 0.36 | 7600.0 | 12 |
| R073314040 | 40.0 | 9680.0 | 0.36 | 7600.0 | 12 |
| R073304000 | 40.0 | 9680.0 | 0.36 | 7600.0 | 12 |
| R073323045 | 30.0 | 6300.0 | 0.18 | 5230.0 | 13.5 |
| R073323040 | 30.0 | 6300.0 | 0.18 | 5230.0 | 9 |
| R073313040 | 30.0 | 6300.0 | 0.18 | 5230.0 | 9 |
| R073303000 | 30.0 | 6300.0 | 0.18 | 5230.0 | 9 |
| R073322545 | 25.0 | 4430.0 | 0.14 | 3360.0 | 10.5 |
| R073322540 | 25.0 | 4430.0 | 0.14 | 3360.0 | 7 |
| R073312540 | 25.0 | 4430.0 | 0.13 | 3360.0 | 7 |
| R073302500 | 25.0 | 4430.0 | 0.14 | 3360.0 | 7 |
| R073322045 | 20.0 | 2520.0 | 0.07 | 1880.0 | 7.5 |
Common to all listed parts
| Version | Standard |
| Type | Linear bushing |
| Lubrication | Not lubricated |
| Note: dynamic load capacity C | The load capacities apply for the main direction of loading. |
| Maximum acceleration rate amax [m/s²] | 150.0 |
| Maximum permissible linear speed vmax [m/s] | 5.0 |
| Permissible ambient temperature (min. ... max.) | -20 °C ... +80 °C |
| Friction coefficient μ | 0.001 ... 0.004 |
