Schneider Electric ZBRM22BA0
Wireless and battery less handy box, 1 double action and 1 simple action buttons
- MPN
- ZBRM22BA0
- EAN
- 3606480891120
Price and lead time confirmed within 1 business day
Discontinued by Schneider Electric — we can still source the original ZBRM22BA0 (new, used or refurbished, subject to availability). Request a quote below.
Request a Quote
- 1We check stock, condition and lead time
- 2You get a written quote by email
- 3Approve it and we ship — in-stock parts within 1 business day
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- 100% positive eBay feedback
- Ships via
What is the Schneider Electric ZBRM22BA0?
Schneider Electric wireless and battery less handy box, 1 double action and 1 simple action buttons, manufacturer part number ZBRM22BA0. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.
Specifications
Specifications
| Range of product | Harmony XB5R |
| Product or component type | Wireless and batteryless transmitter |
| Device short name | XB5R |
| Contact operation | 1 simple and double action UP/DOWN push-buttons |
| Bezel material | Plastic |
| Fixing collar material | Plastic |
| Mounting diameter | 22 mm |
| Kit composition | 1 transmitter, 1 set of caps, 1 handy box, 2 push-button head diameter: 22 mm, 2 fixing collars |
| Shape of signaling unit head | Round |
| Type of operator | Spring return push-button with transmitter |
| Operator profile | Flush |
| Operator additional information | Set of caps |
| Net weight | 0.2 kg |
| Mechanical durability | 400000 cycles |
| Operating travel | 4.3 mm (total travel) |
| Operating force | 25 N C/O changing electrical state |
| Shock resistance | 25 gn (duration = 6 ms) for 6000 shocks conforming to IEC 60068-2-27, 30 gn (duration = 18 ms) for half sine wave acceleration conforming to IEC 60068-2-27, 50 gn (duration = 11 ms) for half sine wave acceleration conforming to IEC 60068-2-27 |
| Mechanical robustness | Free fall resistance 1000 mm conforming to EN/IEC 60068-2-32 |
| Communication port protocol | Zigbee green power at 2.4 GHz |
| Maximum sensing distance | 100 m in free field, 25 m transmitter in the handy box and receiver in a metal enclosure, 300 m transmitter in the handy box, receiver in metal enclosure and use relay-antenna |
| Acquisition time | 2 ms |
| Response time | < 2 ms |
| Emission power | 3 mW |
| Ambient air temperature for storage | -40…70 °C |
| Ambient air temperature for operation | -25…55 °C |
| IP degree of protection | IP65 (front face) conforming to IEC 60529, IP65 (front face) conforming to UL Type 12 |
| IK degree of protection | IK03 conforming to IEC 50102 |
| Relative humidity | 95 % at 70 °C without condensation |
| Vibration resistance | 5 gn (f= 11…500 Hz) conforming to IEC 60068-2-6, +/- 10 mm (f= 2…11 Hz) conforming to IEC 60068-2-6 |
| Electromagnetic compatibility | Electrostatic discharge immunity test - test level: 8 kV (in free air (in insulating parts)) conforming to IEC 61000-4-2, Electrostatic discharge immunity test - test level: 4 kV (on contact (on metal parts)) conforming to IEC 61000-4-2, Susceptibility to electromagnetic fields - test level: 20 V/m (80...3000 MHz) conforming to IEC 61000-4-3, Susceptibility to electromagnetic fields - test level: 6 V/m (3000...6000 MHz, distance = 20 m) conforming to IEC 61000-4-3 |
| Radio agreement | RSS conforming to UL 508, ARIB T66 conforming to CSA C22.2 No 14, ICASA, ANATEL, FCC |
| Standards | CSA C22.2 No 14, EN/IEC 60947-1, EN/IEC 60947-5-1, UL 508 |
| Product certifications | CSA, UL, CCC, C-Tick, BT 2006/95/EC, EAC |
| Directives | 1999/5/EC - R&TTE directive, 2004/108/EC - electromagnetic compatibility |
Packaging
| Package 1 | 1 PCE, 16.3 cm × 6.5 cm × 6.5 cm (L × W × H), 232.0 g |
No matching specifications
Downloads & documentation
Official documents from Schneider Electric, downloaded directly from the manufacturer.
Data sheets & manuals
ZBRM22BA0: frequently asked questions
Can I still buy the ZBRM22BA0 now that it is discontinued?
Yes. Schneider Electric has discontinued the ZBRM22BA0, but sourcing discontinued parts is what PartnerPLC specialises in — new old stock, used and refurbished units. Request a quote and we'll confirm availability, condition and lead time.
When can ZBRM22BA0 be shipped?
ZBRM22BA0 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up ZBRM22BA0 in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for ZBRM22BA0 and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for ZBRM22BA0, subject to availability and destination.
