Schneider Electric XB5RFB01
Wireless and batteryless package, Harmony XB5R, Wireless push button and non configurable receiver, plastic, 22mm, with 1 black cap, 24V DC
- MPN
- XB5RFB01
- EAN
- 3606480334443
Price and lead time confirmed within 1 business day
Request a Quote
- 1We check stock, condition and lead time
- 2You get a written quote by email
- 3Approve it and we ship — in-stock parts within 1 business day
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- 100% positive eBay feedback
- Ships via
What is the Schneider Electric XB5RFB01?
This Harmony XB5, flush black wireless push button and receiver unit set is supplied with a 24V DC input. This wireless batteryless push button provides a simple and reliable solution for remote control of machines, conveyors and cranes. The button is easily installed into standard 22mm diameter panel cut-outs, while the receiver is DIN rail mountable. Its plastic bezel makes it ideal for applications requiring good resistance to chemical agents and/or double electrical insulation. It provides robust wireless communications, for guaranteed operation even in the most electromagnetically disturbed environments. Its simple modular design facilitates post installation servicing, modification and adaption of machines by non-specialists. It is easily installed into standard 22mm diameter cut-outs. It complies with most radio emission standards, for a guaranteed comfort during design and project approval.
Specifications
Specifications
| Range of product | Harmony XB5R |
| Product or component type | Wireless and batteryless package |
| Device short name | XB5R |
| Head material | Plastic |
| frequency | 2405 MHz for transmitter, 2405 MHz for receiver |
| emission class | 5M00G7W |
| Antenna type | Omnidirectional |
| Control type | Wireless and batteryless push-button Ø 22 mm assembled on fixing collar |
| Type of receiver | Non-programmable receiver (1 relay) |
| [Us] rated supply voltage | 24 V |
| Kit composition | 1 transmitter, 1 set of caps, 1 receiver, 1 fixing collars, 1 diameter: 22 mm, 1 push-button head diameter: 22 mm |
| Communication port protocol | Zigbee conforming to IEEE 802.15.4 |
| Max power consumption in W | 1 mW |
| Number of channels | 1 |
| Modulation Technique | O-QPSK |
| Bandwidth | 5 MHz |
| Antenna gain | 0 dBi |
| Product certifications | UL, C-Tick, GOST, CSA, CCC |
| Marking | CE |
| Standards | IEC 60947-5-1, CSA C22.2 No 14, IEC 60947-1, UL 508 |
| Radio agreement | SRRC, ICASA, RSS, ANATEL, FCC, ARIB T66 |
Packaging
| Package 1 | 1 PCE, 10.800 cm × 10.500 cm × 9.300 cm (L × W × H), 195.000 g |
| Package 2 | 16 S03, 40.000 cm × 30.000 cm × 30.000 cm (L × W × H), 3.666 kg |
