Schneider Electric XB4RFB01
Wireless and batteryless package, Harmony XB5R, Wireless metal 22mm black pushbutton, non configurable receiver, 24V DC
- MPN
- XB4RFB01
- EAN
- 3606480436024
Price and lead time confirmed within 1 business day
Request a Quote
- 1We check stock, condition and lead time
- 2You get a written quote by email
- 3Approve it and we ship — in-stock parts within 1 business day
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- 100% positive eBay feedback
- Ships via
What is the Schneider Electric XB4RFB01?
This ready-to-use pack is part of the range diameter 22mm wireless and batteryless pushbuttons XB4R metal. This pack comprises one wireless and batteryless metallic pushbutton assembled on fixing collar and one receiver. Pushbutton and receiver are factory-paired. The wireless and batteryless pushbutton reduces installation time and cost by eliminating wiring and associated equipment between the transmitters and the control panel. This technology also allows an operator to be mobile or have a control mounted on-board of a vehicle (trolley, truck, etc.). The pushbutton is always available and requires no maintenance (no battery needed).
Specifications
Specifications
| Range of product | Harmony XB4R |
| Product or component type | Wireless and batteryless package |
| Device short name | XB4R |
| Head material | Metal |
| frequency | 2405 MHz for transmitter, 2405 MHz for receiver |
| emission class | 5M00G7W |
| Antenna type | Omnidirectional |
| Control type | Wireless and batteryless push-button Ø 22 mm assembled on fixing collar |
| Type of receiver | Non-programmable receiver (1 relay) |
| [Us] rated supply voltage | 24 V |
| Kit composition | 1 fixing collars, 1 diameter: 22 mm, 1 push-button head diameter: 22 mm, 1 transmitter, 1 receiver, 1 set of caps |
| Communication port protocol | Zigbee conforming to IEEE 802.15.4 |
| Max power consumption in W | 1 mW |
| Number of channels | 1 |
| Modulation Technique | O-QPSK |
| Bandwidth | 5 MHz |
| Antenna gain | 0 dBi |
| Product certifications | CCC, C-Tick, GOST, CSA, UL |
| Marking | CE |
| Standards | UL 508, IEC 60947-1, CSA C22.2 No 14, IEC 60947-5-1 |
| Radio agreement | ARIB T66, RSS, ICASA, SRRC, FCC, ANATEL |
Packaging
| Package 1 | 1 PCE, 11.000 cm × 10.500 cm × 9.300 cm (L × W × H), 235.000 g |
| Package 2 | 16 S03, 40.000 cm × 30.000 cm × 30.000 cm (L × W × H), 4.000 kg |
