Schneider Electric XB4RFA02
Wireless push button and configurable receiver, Harmony XB5R, Harmony XB4, with 10 colored caps, metal, 22mm, 24...240V AC DC
- MPN
- XB4RFA02
- EAN
- 3606480436031
Price and lead time confirmed within 1 business day
Request a Quote
- 1We check stock, condition and lead time
- 2You get a written quote by email
- 3Approve it and we ship — in-stock parts within 1 business day
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- 100% positive eBay feedback
- Ships via
What is the Schneider Electric XB4RFA02?
This Harmony XB4 flush wireless and batteryless push button and receiver unit set is supplied with a set of 10 colored caps and uses a 24V to 240V AC input. It has a metal bezel. This wireless batteryless push button provides a simple and reliable solution for remote control of machines, conveyors and cranes. The button is easily installed into standard 22mm diameter panel cut-outs, while the receiver is DIN rail mountable.
Specifications
Specifications
| Range of product | Harmony XB4R |
| Product or component type | Wireless and batteryless package |
| Device short name | XB4R |
| Head material | Metal |
| frequency | 2405 MHz for transmitter, 2405 MHz for receiver |
| emission class | 5M00G7W |
| Antenna type | Omnidirectional |
| Control type | Wireless and batteryless push-button Ø 22 mm assembled on fixing collar |
| Type of receiver | Programmable receiver (2 relays) |
| [Us] rated supply voltage | 24...240 V |
| Kit composition | 1 diameter: 22 mm, 1 push-button head diameter: 22 mm, 1 receiver, 1 set of caps, 1 fixing collars, 1 transmitter |
| Status LED | 1 LED green for power ON, 2 LEDs green for relay ON, 2 LEDs green for function mode, 1 LED green and yellow for reception signal |
| Communication port protocol | Zigbee conforming to IEEE 802.15.4 |
| Max power consumption in W | 1 mW |
| Number of channels | 1 |
| Modulation Technique | O-QPSK |
| Bandwidth | 5 MHz |
| Antenna gain | 0 dBi |
| Product certifications | GOST, CCC, CSA, UL, C-Tick |
| Marking | CE |
| Standards | IEC 60947-1, IEC 60947-5-1, CSA C22.2 No 14, UL 508 |
| Radio agreement | ANATEL, FCC, RSS, ARIB T66, ICASA, SRRC |
Packaging
| Package 1 | 1 PCE, 10.800 cm × 10.500 cm × 9.200 cm (L × W × H), 250.000 g |
| Package 2 | 16 S03, 40.000 cm × 30.000 cm × 30.000 cm (L × W × H), 4.459 kg |
