Schneider Electric SURT5KSR3UXIX438

APC Smart-UPS RT 5000VA, 230V, with AP9610, hardwired I/O, for 600mm deep rack, 3U, 1x hard wire 3-wire (H N + E)

MPN
SURT5KSR3UXIX438
Price and lead time confirmed within 1 business day
Request a Quote
  1. 1We check stock, condition and lead time
  2. 2You get a written quote by email
  3. 3Approve it and we ship — in-stock parts within 1 business day

A real person replies, typically within 1 business day — see our privacy policy.

  • 12-month warranty (new) · 3-month (used/refurbished)
  • 30-day returns, no restocking fee on unused parts
  • 100% positive eBay feedback
  • Ships via

Have spare Schneider Electric parts? We buy surplus →

What is the Schneider Electric SURT5KSR3UXIX438?

The APC Smart-UPS RT is an online UPS with a power rating of 5000VA and output power capacity of 4000 watts. This model is includes a lead-acid battery and is not rack-mountable. The UPS features double conversion online technology and sine wave output.

Specifications

Specifications

PresentationProven Industrial UPS power protection for control applications and harsh environments.
Max. Capacity Used
Main Input Voltage230 V
Input voltage208 V, 220 V, 240 V
Input voltage limits160...280 V
Number of input connectors1 hard wire 3-wire
Network frequency50/60 Hz +/- 3 Hz auto-sensing
Output voltage220 V, 240 V
Rated power in W4000 W
rated power in VA5000 VA
Output connector typeHard wire 3-wire (H N + E) for 1 zone(s)
Bypass typeInternal bypass (automatic and manual)
Crest factor3 : 1
Harmonic distortionLess than 3 %
UPS typeOn-Line
Wave typeSine wave
Efficiency92 % (full load)
Output frequency50/60 Hz +/- 3 Hz user adjustable +/- 0.1 Hz sync to mains
Free slots0
AlarmAlarm when on battery : distinctive low battery alarm : overload continuous tone alarm
Let through voltage rating300 V
Surge energy rate480 J
Noise suppressionFull time multi-pole noise filtering : 0.3% IEEE surge let-through : zero clamping response time : meets UL 1449
Number of rack unit3U
Height133 mm
Width432 mm
Depth545 mm
Net weight18.18 kg
Mounting preferenceNo preference
Mounting modeRack-mounted
Two post mountable0
USB compatibleNo
Provided equipmentCD with software, Documentation CD, Relay board, Smart UPS signalling RS-232 cable, User manual
Number of power module filled slots0
Number of power module free slots0
RedundantNo
Variant optionIndustrial
Product or component typeUninterruptible power supply (UPS)
Product certificationscUL listed, CE, FCC part 15 class A, VDE
StandardsEN/IEC 62040-1:2019/A11:2021, EN/IEC 62040-2:2006/AC:2006, EN/IEC 62040-2:2018
Ambient air temperature for operation0…40 °C
Ambient air temperature for storage-15…45 °C
Storage altitude0…15240 m
Relative humidity0…95 %
Storage Relative Humidity0…95 %
Acoustic level55 dBA
Heat dissipation1040 Btu/h
Operating altitude0...10000 ft
Run TimeView Runtime Graph
Battery typeExternal battery system
Extended runtime1
Number of battery filled slots0
Number of battery free slots0
Battery recharge time2.5 h
Number of battery replacement quantity1
Battery charger power382 W rated

Packaging

Package 11 PCE, 50.8 cm × 61 cm × 25.4 cm (L × W × H), 20.45 kg

Downloads & documentation

Official documents from Schneider Electric, downloaded directly from the manufacturer.

Data sheets & manuals

SURT5KSR3UXIX438: frequently asked questions

When can SURT5KSR3UXIX438 be shipped?

SURT5KSR3UXIX438 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up SURT5KSR3UXIX438 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for SURT5KSR3UXIX438 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for SURT5KSR3UXIX438, subject to availability and destination.
