What is the Schneider Electric LXM62DD15B21000?

Schneider Electric LXM62DD15B21000 — Lexium 62 Double Drive - accessory kit included. Discontinued by Schneider Electric; the manufacturer's successor is LXM62DD15D21000. PartnerPLC sources discontinued and surplus Schneider Electric automation parts — request a quote for price, condition and lead time.

Specifications

Main

Range of productPacDrive 3
Device short nameLXM 62
Product or component typeDouble drive
Component nameLXM62

Complementary

Network number of phasesThree phase
[Us] rated supply voltage400 V (- 10...10 %) for three phase; 230 V (- 10...10 %) for three phase; 230 V (- 10...10 %) for single phase
Supply frequency50/60 Hz - 5...5 %
Continuous output current5 A at 4 kHz
Output current 3s peak15 A at 4 kHz
Switching frequency8 kHz
Overvoltage categoryIII
Electrical connectionTerminal, clamping capacity: 0.2...15 mm², 24 AWG...16 AWG (CN4); Terminal, clamping capacity: 0.5...16 mm², 20 AWG...6 AWG (CN5); Terminal, clamping capacity: 0.75...16 mm², 18 AWG...6 AWG (CN6); Terminal, clamping capacity: 0.2...6 mm², 24 AWG...10 AWG (CN7)
Tightening torqueCN1: 2.5 N.m
Number of inputs2 digital; 2 touch probe
Discrete input voltage24 V DC for - 20...25 %
Number of outputs2 digital
Discrete output voltage24 V DC
Safety functionSTO (safe torque off)
Communication interfaceSERCOS III, integrated
Net weight3 kg

Environment

StandardsIEC 61800-3; IEC 61800-5-1; IEC 62061; IEC 61800-5-2; CSA C22.2 No 14; ISO 13849-1; IEC 61508; UL 508C; ISO 13849-2
Product certificationsCE; TÜV; CSA; EAC; UL
IP degree of protectionIP20 conforming to IEC 60529
Vibration resistance10 m/s² conforming to IEC 60721-3-3
Shock resistance100 m/s² conforming to IEC 60721-3-3
Pollution degree2 conforming to IEC 61800-5-2
Environmental characteristic3K3 conforming to IEC 60721-3-3
Relative humidity5…85 %
Ambient air temperature for operation5…55 °C

Downloads & documentation

Official documents from Schneider Electric, downloaded directly from the manufacturer.

Data sheets & manuals

LXM62DD15B21000: frequently asked questions

Can I still buy the LXM62DD15B21000 now that it is discontinued?

Yes. Schneider Electric has discontinued the LXM62DD15B21000, but sourcing discontinued parts is what PartnerPLC specialises in — new old stock, used and refurbished units. Request a quote and we'll confirm availability, condition and lead time. If you are planning an upgrade instead, Schneider Electric names the LXM62DD15D21000 as its successor — we can quote both.

When can LXM62DD15B21000 be shipped?

LXM62DD15B21000 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up LXM62DD15B21000 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for LXM62DD15B21000 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for LXM62DD15B21000, subject to availability and destination.
