Schneider Electric LXM52DU60C41000
LXM52 single drive 1,5A/6A
- MPN
- LXM52DU60C41000
- EAN
- 3606480517303
- Category
- Servo & Motion Control
Request a Quote
- 1We check stock, condition and lead time
- 2You get a written quote by email
- 3Approve it and we ship — in-stock parts within 1 business day
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- 100% positive eBay feedback
- Ships via
What is the Schneider Electric LXM52DU60C41000?
This product is part of the Lexium 52 & Motors range, an offer of standalone servo drives for PacDrive 3. The single drive features SERCOS III physical interface. It offers 4 digital/4 touch probe inputs and 2 digital outputs. It is a single drive with a rated supply voltage of 208V to 480V, a continuous output current of 1.5A and a continuous power of 0.4kW. It is furnished with connector terminals for electrical connection. It is an IP20 rated product. It weighs 1.8kg. It is suitable for general machine control, packaging machine automation and material handling applications. This product is certified by CE and UL. It meets EN/IEC 61800-3 and EN/IEC 61800-5-1 standards. This product is compatible with servo motor SH3 (55mm, 1 motor stack), servo motor SH3 (55mm, 2 motor stacks) and servo motor SH3 (70mm, 2 motor stacks). Lexium 52 provides an ideal counterbalance to the Lexium 62 multi-axis servo system, making the PacDrive system one of the most flexible motion control solutions. Lexium Stand alone servo drives from 0.4kW and 7kW for PacDrive based automation solutions. PartnerPLC sources new and surplus Schneider Electric automation parts — request a quote for price, condition and lead time.
Specifications
Main
| Range of product | PacDrive 3 |
| Device short name | LXM 52 |
| Product or component type | Single drive |
| Product compatibility | Servo motor SH3 (55 mm, 1 motor stacks)optimized in terms of torque and speed; Servo motor SH3 (55 mm, 2 motor stacks)optimized in terms of torque and speed; Servo motor SH3 (70 mm, 2 motor stacks)optimized in terms of high torque; Servo motor MH3 (70 mm, 1 motor stacks)optimized in terms of torque and speed |
| Component name | LXM52 |
Complementary
| Network number of phases | Three phase |
| [Us] rated supply voltage | 208...480 V - 15...10 % |
| Supply frequency | 50...60 Hz - 5...5 % |
| Continuous output current | 1.5 A at 8 kHz |
| Output current 3s peak | 6 A |
| Continuous power | 0.8 kW |
| Nominal power | 0.4 kW |
| Switching frequency | 8 kHz |
| Overvoltage category | III |
| Electrical connection | Terminal, clamping capacity: 0.75...5.3 mm², 18 AWG...10 AWG (CN1); Terminal, clamping capacity: 0.75...5.3 mm², 18 AWG...10 AWG (CN10) |
| Tightening torque | CN1: 0.68 N.m; CN10: 0.68 N.m |
| Number of inputs | 4 digital; 4 touch probe |
| Discrete input voltage | 24 V DC |
| Number of outputs | 2 digital |
| Discrete output voltage | 24 V DC |
| Contact bounce time | > 1 ms for compliment of STO_A, compliment of STO_B |
| Communication interface | SERCOS III, integrated |
| Width | 48 mm |
| Height | 270 mm |
| Depth | 217 mm |
| Net weight | 1.8 kg |
Environment
| Standards | IEC 61800-3; IEC 61800-5-1 |
| Product certifications | CE; UL |
| IP degree of protection | IP20 conforming to IEC 60721-3-3 |
| Vibration resistance | 10 m/s² conforming to IEC 60721-3-3 |
| Shock resistance | 100 m/s² conforming to IEC 60721-3-3 |
| Pollution degree | 2 |
| Environmental characteristic | 3K3 conforming to IEC 60721-3-3 |
| Relative humidity | 5…95 % |
| Ambient air temperature for operation | 0…50 °C |
