Schneider Electric LXM52DD72C41000 – LXM52 single drive 24A/72A

Name: Schneider Electric LXM52DD72C41000 – LXM52 single drive 24A/72A
Brand: Schneider Electric
SKU: LXM52DD72C41000

MPN: LXM52DD72C41000 · Brand: Schneider Electric

Price on request

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	Servo & Motion Control
Lifecycle	Active
Warranty	12-month (new) · 3-month (used/refurbished)
Country of origin	ID
UPC / EAN	3606480517334
Datasheet	Manufacturer datasheet ↗

Shipping & availability

When can LXM52DD72C41000 be shipped?

LXM52DD72C41000 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up LXM52DD72C41000 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for LXM52DD72C41000 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for LXM52DD72C41000, subject to availability and destination.

This product is part of the Lexium 52 & Motors range, an offer of standalone servo drives for PacDrive 3. The single drive features SERCOS III physical interface. It offers 4 digital inputs and 2 digital outputs. It is a single drive with a rated supply voltage of 208V to 480V, a continuous output current of 13A and a continuous power of 7kW. It is furnished with connector terminals for electrical connection. It is an IP20 rated product. It weighs 5kg. It is suitable for general machine control, packaging machine automation and material handling applications. This product is certified by CE. It meets EN/IEC 61800-3 standards. This product is compatible with servo motor SH3 (100mm, 4 motor stacks), servo motor SH3 (140mm, 2 motor stacks) and servo motor SH3 (140mm, 3 motor stacks). Lexium 52 provides an ideal counterbalance to the Lexium 62 multi-axis servo system, making the PacDrive system one of the most flexible motion control solutions. Lexium Stand alone servo drives from 0.4kW and 7kW for PacDrive based automation solutions. PartnerPLC sources new and surplus Schneider Electric automation parts — request a quote for price, condition and lead time.

Specifications

Main

Range of product	PacDrive 3
Device short name	LXM 52
Product or component type	Single drive
Product compatibility	Servo motor SH3 (100 mm, 4 motor stacks)optimized in terms of torque and speed; Servo motor SH3 (140 mm, 2 motor stacks)optimized in terms of torque and speed; Servo motor SH3 (140 mm, 3 motor stacks)optimized in terms of torque and speed; Servo motor SH3 (140 mm, 4 motor stacks)optimized in terms of torque and speed; Servo motor SH3 (205 mm, 1 motor stacks)optimized in terms of torque and speed; Servo motor SH3 (205 mm, 2 motor stacks)optimized in terms of torque and speed; Servo motor SH3 (205 mm, 3 motor stacks)optimized in terms of torque and speed; Servo motor MH3 (140 mm, 2 motor stacks)optimized in terms of torque and speed; Servo motor MH3 (140 mm, 3 motor stacks)optimized in terms of torque and speed; Servo motor MH3 (190 mm, 1 motor stacks)optimized in terms of torque and speed; Servo motor MH3 (190 mm, 2 motor stacks)optimized in terms of torque and speed; Servo motor MH3 (190 mm, 3 motor stacks)optimized in terms of torque and speed
Component name	LXM52

Complementary

Network number of phases	Three phase
[Us] rated supply voltage	208...480 V - 15...10 %
Supply frequency	50...60 Hz - 5...5 %
Continuous output current	13 A at 8 kHz
Output current 3s peak	72 A
Continuous power	13 kW
Nominal power	7 kW
Switching frequency	8 kHz
Overvoltage category	III
Electrical connection	Terminal, clamping capacity: 0.75...10 mm², 18 AWG...8 AWG (CN1)
Tightening torque	CN10: 0.68 N.m
Number of inputs	4 digital
Discrete input voltage	24 V DC
Number of outputs	2 digital
Discrete output voltage	24 V DC
Contact bounce time	> 1 ms for compliment of STO_A, compliment of STO_B
Communication interface	SERCOS III, integrated
Width	108 mm
Height	274.1 mm
Depth	217 mm
Net weight	5 kg

Environment

Standards	IEC 61800-3
Product certifications	CE
IP degree of protection	IP20 conforming to IEC 60721-3-3
Vibration resistance	10 m/s² conforming to IEC 60721-3-3
Shock resistance	100 m/s² conforming to IEC 60721-3-3
Pollution degree	2
Environmental characteristic	3K3 conforming to IEC 60721-3-3
Relative humidity	5…95 %
Ambient air temperature for operation	0…50 °C
