Schneider Electric EMS58583
PowerLogic BAT38Ah 12V 38Ah 10 years life high rate industrial VRLA battery
- MPN
- EMS58583
- EAN
- 3606480461217
- Category
- PowerLogic™ T300
Price and lead time confirmed within 1 business day
Request a Quote
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- Ships via
- 100% positive eBay feedback
What is the Schneider Electric EMS58583?
The Easergy T300 battery are designed for long power supply The output voltage is 12VDC The battery life is 10 years The operating temperature is -15°C to + 50°C during the charge and -20°C to + 60°C during the discharge. The storage temperature is -20°C to + 60°C. Mechanical dimensions are 170 mm in height, 165 mm in width and 197 mm in depth.
Specifications
Specifications
| Range of product | PowerLogic T300 |
| Product compatibility | PS50, PS100, ITI3 |
| Device short name | BAT38AH |
| Output voltage | 12 V DC |
| Battery type | VRLA |
| Internal resistance | 14.4 mOhm conforming to IEC 60896-21 |
| Short-circuit current | 1005 A conforming to IEC 60896-21 |
| Transfer impedance | 7.5 mOhm at 1 kHz |
| Battery capacity | 40.6 Ah |
| Height | 170 mm |
| Width | 165 mm |
| Depth | 197 mm |
| Net weight | 14.5 kg |
| Connector type | M5 |
| tightening torque | 2.5 N.m |
| Self-discharge rate | 3 %, 1 month at 20 °C |
| Battery life | 10 year(s) at 20 °C conforming to EUROBAT |
| Ambient air temperature for operation | -15…50 °C charge, -20…60 °C discharge |
| Ambient air temperature for storage | -20…60 °C |
Packaging
| Package 1 | 1 PCE, 20.500 cm × 17.400 cm × 18.000 cm (L × W × H), 14.272 kg |
| Package 2 | 16 P12, 120.000 cm × 80.000 cm × 35.000 cm (L × W × H), 240.944 kg |
Downloads & documentation
Official documents from Schneider Electric, downloaded directly from the manufacturer.
Data sheets & manuals
EMS58583: frequently asked questions
When can EMS58583 be shipped?
EMS58583 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up EMS58583 in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for EMS58583 and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for EMS58583, subject to availability and destination.
