Schneider Electric EMS58582
PowerLogic BAT24Ah 12V 24Ah 10 years life high rate industrial VRLA battery
- MPN
- EMS58582
- EAN
- 3606480461200
- Category
- PowerLogic™ T300
Price and lead time confirmed within 1 business day
Request a Quote
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- Ships via
- 100% positive eBay feedback
What is the Schneider Electric EMS58582?
The Easergy T300 battery are designed for long power supply The output voltage is 12VDC The battery life is 10 years The operating temperature is -15°C to + 50°C during the charge and -20°C to + 60°C during the discharge. The storage temperature is -20°C to + 60°C. Mechanical dimensions are 125 mm in height, 175 mm in width and 166 mm in depth.
Specifications
Specifications
| Range of product | PowerLogic T300 |
| Product compatibility | PS50, PS100, ITI3 |
| Device short name | BAT24AH |
| Output voltage | 12 V DC |
| Battery type | VRLA |
| Internal resistance | 20.47 mOhm conforming to IEC 60896-21 |
| Short-circuit current | 714 A conforming to IEC 60896-21 |
| Transfer impedance | 8.5 mOhm at 1 kHz |
| Battery capacity | 25 Ah |
| Height | 125 mm |
| Width | 175 mm |
| Depth | 166 mm |
| Net weight | 9.8 kg |
| Connector type | M5 |
| tightening torque | 2.5 N.m |
| Self-discharge rate | 3 %, 1 month at 20 °C |
| Battery life | 10 year(s) at 20 °C conforming to EUROBAT |
| Ambient air temperature for operation | -15…50 °C charge, -20…60 °C discharge |
| Ambient air temperature for storage | -20…60 °C |
Packaging
| Package 1 | 1 PCE, 19.600 cm × 18.600 cm × 13.300 cm (L × W × H), 9.785 kg |
| Package 2 | 48 P12, 120.000 cm × 80.000 cm × 42.000 cm (L × W × H), 480.672 kg |
