Schneider Electric 170ADO53050

Discrete output module Modicon Momentum - 8 O solid state

MPN
170ADO53050
EAN
3595861147553
Price and lead time confirmed within 1 business day

Discontinued by Schneider Electric — we can still source the original 170ADO53050 (new, used or refurbished, subject to availability). Request a quote below.

Request a Quote
  1. 1We check stock, condition and lead time
  2. 2You get a written quote by email
  3. 3Approve it and we ship — in-stock parts within 1 business day

A real person replies, typically within 1 business day — see our privacy policy.

  • 12-month warranty (new) · 3-month (used/refurbished)
  • 30-day returns, no restocking fee on unused parts
  • 100% positive eBay feedback
  • Ships via

Have spare Schneider Electric parts? We buy surplus →

What is the Schneider Electric 170ADO53050?

This output module is part of the Modicon Momentum range, an offer of controller and IP20 monoblock I/Os for distributed control architecture. This discrete output base AC module offers 2 groups of 16 outputs, 32 discrete outputs with triac type. It offers discrete output voltage of 120V AC. There is an isolation between the channels and the bus at 1780V AC. It features 16 LEDs for channel status signaling. Its dimensions are 125mm (width) x 47.5mm (depth) x 141.5mm (height), and it weighs approximately 0.32 kg. The main application of this module is infrastructures and energy, material handling, simple machine control. This product is certified by CE, FM Class 1 Division 2, CSA and UL. It is suitable for wall mount. Momentum is a flexible, modular family of components that easily snaps together and can be configured for a wide range of distributed I/O and control applications. System with 4 fundamental components that easily snap together in various combinations to form versatile control systems or sub-systems. Discontinued by Schneider Electric; the manufacturer's successor is NTSDAO0415K. PartnerPLC sources discontinued and surplus Schneider Electric automation parts — request a quote for price, condition and lead time.

Specifications

Main

Range of productModicon Momentum automation platform
Product or component typeDiscrete output base AC
Group of channels2 groups of 4 outputs
Current per channel2 A
Discrete output number8

Complementary

Output overload protectionInternal fuse
Terminals description PLC n°1(4)OUT_DIS#4; (2)OUT_DIS#2; (1)OUT_DIS#1; (3)OUT_DIS#3; (1L+)PW; TB; (5)OUT_DIS#5; (6)OUT_DIS#6; (1N)PW; (7)OUT_DIS#7; (8)OUT_DIS#8
Local signalling8 LEDs for channel status
Height141.5 mm
Width125 mm
Depth47.5 mm
Net weight0.32 kg

Environment

Protective treatmentTC
MarkingCE

Downloads & documentation

Official documents from Schneider Electric, downloaded directly from the manufacturer.

Data sheets & manuals

170ADO53050: frequently asked questions

Can I still buy the 170ADO53050 now that it is discontinued?

Yes. Schneider Electric has discontinued the 170ADO53050, but sourcing discontinued parts is what PartnerPLC specialises in — new old stock, used and refurbished units. Request a quote and we'll confirm availability, condition and lead time. If you are planning an upgrade instead, Schneider Electric names the NTSDAO0415K as its successor — we can quote both.

When can 170ADO53050 be shipped?

170ADO53050 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 170ADO53050 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 170ADO53050 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 170ADO53050, subject to availability and destination.
