Schneider Electric 170AEC92000

Modicon Momentum - high speed counter module base - 6 I / 4 O

MPN
170AEC92000
EAN
3595861147744
Price and lead time confirmed within 1 business day
Request a Quote
  1. 1We check stock, condition and lead time
  2. 2You get a written quote by email
  3. 3Approve it and we ship — in-stock parts within 1 business day

A real person replies, typically within 1 business day — see our privacy policy.

  • 12-month warranty (new) · 3-month (used/refurbished)
  • 30-day returns, no restocking fee on unused parts
  • 100% positive eBay feedback
  • Ships via

Have spare Schneider Electric parts? We buy surplus →

What is the Schneider Electric 170AEC92000?

This counter module is part of the Modicon Momentum range, an offer of controller and IP20 monoblock I/Os for distributed control architecture. This high speed counter module base has 2 groups of 3 discrete inputs and 2 groups of 2 discrete outputs with positive discrete input logic. It is a module with discrete input voltage ranges from -3V DC to 30V DC, 24V DC and discrete output voltage of 24V. It is furnished with 2 removable terminal blocks for electrical connection. It weighs 0.21kg. The main application of this module is infrastructures and energy, material handling, simple machine control. This product is certified by CE, CSA and UL. It is suitable for wall mount. Momentum is a flexible, modular family of components that easily snaps together and can be configured for a wide range of distributed I/O and control applications. System with 4 fundamental components that easily snap together in various combinations to form versatile control systems or sub-systems.

Specifications

Specifications

Range of productModicon Momentum automation platform
Product or component typeHigh speed counter module base
Group of channels2 groups of 3 discrete inputs, 2 groups of 2 discrete outputs
Number of counter2
Discrete input number6
Discrete output number4
Discrete input logicPositive
Discrete input voltage- 3...30 V DC, 24 V DC
Input overvoltage protection45 V 10 s
Voltage state 1 guaranteed>= 11 V
Voltage state 0 guaranteed<= 5 V
Current state 1 guaranteed>= 2.5 mA
Current state 0 guaranteed<= 1.2 mA
Discrete output logicPositive
Discrete output voltage24 V
Discrete output current1 A per counter, 2 A per module, 0.5 A per point
Maximum voltage drop<0.5 V 0.5 A at state on
Maximum leakage current1 mA DC 24 V
Surge current5 A 1 ms
Response time< 0.1 ms from state 0 to state 1 output circuit, < 0.1 ms from state 1 to state 0 output circuit, 3 ms from state 0 to state 1 input circuit, 3 ms from state 1 to state 0 input circuit
Counting input typeAbsolute SSI up, down with 4 sub-modes, Incremental up, down, quadrature
Counting input voltage24 V single ended, 5 V differential
Counting frequency10 kHz single ended, 200 kHz differential
Counter inputs resolution24 bits + sign
Counter configurationVia comm adapter
MarkingCE
Electrical connection2 connectors for removable terminal blocks
Current consumption280 mA at 24 V DC
Net weight0.21 kg
Product certificationsUL, CSA
Protective treatmentTC
Resistance to electrostatic discharge4 kV contact conforming to IEC 801-2, 8 kV on air conforming to IEC 801-2
Resistance to electromagnetic fields10 V/m 80...1000 MHz conforming to IEC 801-3
Ambient air temperature for operation0…60 °C
Ambient air temperature for storage-40…85 °C
Relative humidity95 % without condensation
Operating altitude<= 5000 m

Packaging

Package 11 PCE, 26.200 cm × 18.000 cm × 5.800 cm (L × W × H), 356.000 g
Package 28 S03, 40.000 cm × 30.000 cm × 30.000 cm (L × W × H), 3.336 kg
