Mitsubishi Electric MES3-SW1-DR-FR

Mitsubishi Energy measuring Application Software

MPN
MES3-SW1-DR-FR
Price and lead time confirmed within 1 business day

Discontinued by Mitsubishi Electric (Factory Automation) — we can still source the original MES3-SW1-DR-FR (new, used or refurbished, subject to availability). Request a quote below.

Request a Quote
  1. 1We check stock, condition and lead time
  2. 2You get a written quote by email
  3. 3Approve it and we ship — in-stock parts within 1 business day

A real person replies, typically within 1 business day — see our privacy policy.

  • 12-month warranty (new) · 3-month (used/refurbished)
  • 30-day returns, no restocking fee on unused parts
  • 100% positive eBay feedback
  • Ships via

Have spare Mitsubishi Electric (Factory Automation) parts? We buy surplus →

What is the Mitsubishi Electric MES3-SW1-DR-FR?

The Mitsubishi Electric MES3-SW1-DR-FR is a application Software in the Energy measuring. This software supports the specific consumption analysis graph and ledger preparation of daily reports, monthly reports and annual reports from CSV files collected and output by the Mitsubishi Electric EcoWebServerⅢ Energy saving Data Collection Server. Mitsubishi Electric has discontinued it (2026/03 Discontinued); PartnerPLC sources discontinued Mitsubishi parts on the surplus market for maintenance of existing machines. Specifications and manuals below are Mitsubishi Electric's own data.

Specifications

Product

SeriesEnergy measuring
Sales status2026/03 Discontinued (Mitsubishi Electric)
OutlineThis software supports the specific consumption analysis graph and ledger preparation of daily reports, monthly reports and annual reports from CSV files collected and output by the Mitsubishi Electric EcoWebServerⅢ Energy saving Data Collection Server.

General specifications

TypeEnergy Saving Supporting Devices
ModelEngineering Software Daily Monthly Report Software EcoMeasureIII
Model nameMES3-SW1-DR-FR

Software specifications

Language *1English, Chinese
Connection devices: Number of units8 units maximum (combination of following target devices)
Connection devices: Target devicesEcoWebServerIII
Number of virtual measurement pointsMaximum 95 points (Total of 95 points including virtual measurement points for calculating measurement management points and virtual measurement points for input.) * Four arithmetic operations of up to 64 measurement management points (including constants) can be registered in the virtual measurement points for calculation.
Number of virtual measurement point groupsMaximum five groups *Addition/Subtraction calculations for up to 32 virtual measurement points can be registered in the virtual measurement point groups.
Ledger creation function: Ledger creationDaily report creation, monthly report creation, annual report creation
Ledger creation function: Maximum number of itemsThe daily, monthly and annual reports can have up to 2,250 output items.
Ledger creation function: Calculation itemsAnalog (including specific consumption) : Maximum, minimum, average Pulse : Total, maximum, minimum, average Demand : Maximum
Ledger creation function: Number of specific consumptionMaximum 100 points
Operation environment: OSMicrosoft Windows 10 Pro (32bits/64bits)
Operation environment: Required softwareMicrosoft Excel 2016 (32bits,64bits) / 2019 (32bits,64bits)
Operation environment: CPUAs recommended for the operating system
Operation environment: Memory *2As recommended for the operating system
Operation environment: Hard-disk *2 *3Software : Approx. 100MB or more Data : 8GB or more
Operation environment: CD-ROM drive1 drive (for installing software)
Operation environment: LAN10/100/1000BASE-T x1
Operation environment: USB connector (Type A)1 connector (for connecting hardware key)
Operation environment: Display resolution800 x 600 pixels or more
Operation environment: Display color256 colors or more
Number of licenses ( number of computers installed in )・ 1 license per 1 client ・ Hardware key attached (USB) (1 unit)

MES3-SW1-DR-FR: frequently asked questions

Can I still buy the MES3-SW1-DR-FR now that it is discontinued?

Yes. Mitsubishi Electric (Factory Automation) has discontinued the MES3-SW1-DR-FR, but sourcing discontinued parts is what PartnerPLC specialises in — new old stock, used and refurbished units. Request a quote and we'll confirm availability, condition and lead time.

When can MES3-SW1-DR-FR be shipped?

MES3-SW1-DR-FR is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up MES3-SW1-DR-FR in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for MES3-SW1-DR-FR and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for MES3-SW1-DR-FR, subject to availability and destination.
