MES3-EAP1-DA Mitsubishi Energy measuring Application Software

MPN: MES3-EAP1-DA · Brand: Mitsubishi Electric (Factory Automation)

Price on request

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	Mitsubishi Energy measuring – Application Software
Lifecycle	Active
Warranty	12-month (new) · 3-month (used/refurbished)

Shipping & availability

When can MES3-EAP1-DA be shipped?

MES3-EAP1-DA is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up MES3-EAP1-DA in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for MES3-EAP1-DA and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for MES3-EAP1-DA, subject to availability and destination.

The Mitsubishi Electric MES3-EAP1-DA is a application Software in the Energy measuring. Energy saving data analysis software Analysis assitance, visualization and cost-saving system can be realized with integrated function for target management, energy saving and production improvement. Specifications and manuals below are Mitsubishi Electric's own data.

Specifications

Product

Series	Energy measuring
Outline	Energy saving data analysis software Analysis assitance, visualization and cost-saving system can be realized with integrated function for target management, energy saving and production improvement.

Specifications

Category	Energy Saving Supporting Devices
Group	Application Software
Model	Energy Saving Support Software EcoAdviser
Product name	Energy saving data analysis software
Model name	MES3-EAP1-DA
Measuring point settings: Register collection source	Register a collection source and its measuring points.
Measuring point settings: Register collection source: Collection source	EcoWebServerⅢ, Edgecross
Measuring point settings: Register collection source: Number of collection sources	Max. 20 units
Measuring point settings: Register collection source: Number of measuring points	MAX. 5680 points [EcoWebServerⅢ] MAX.255 points per unit [EcoWebServerⅢ(with demand control function)] Demand period (15 minutes): Max. 284 points per unit Demand period (30 minutes): Max. 282 points per unit Demand period (60 minutes): Max. 280 points per unit [Edgecross] Max. 256 points per unit Data type: BOOL, INT, UINT, DINT, UDINT, REAL, LREAL
Measuring point settings: Register manual input measuring point	Register a measuring point other than collection sources.
Measuring point settings: Register product type time period measuring point	Register a measuring points to extract data of one product from multiple types of products.
Measuring point settings: Register product type time period measuring point: Measuring value point Time period measuring point	Select from collection sources’ measuring points or manual input measuring points.
Measuring point settings: Register calculation measuring point	Register a measuring point to calculate measuring points with each other.
Measuring point settings: Register calculation measuring point: Available measuring point	Select from collection sources’ measuring points, manual input measuring points, or product type time period measuring points. ∙ Max. 200 points can be registered per calculation formula. ∙ Max. 4000 letters can be used per calculation formula.
Measuring point settings: Register specific consumption measuring point	Register a measuring point to calculate specific consumption.
Measuring point settings: Register specific consumption measuring point: Energy measuring point Production number measuring point	Select from collection sources’ measuring points, manual input measuring points, product type time period measuring points, or calculation measuring points.
Graph function: Analysis method (Graph type)	Select from time series chart, box plot, pie chart, scatter plot, histogram, or pareto chart.
Graph function: Display interval	Select from hourly, daily, monthly, or yearly. * For an analysis method of box plot, this is set to hourly.
Dashboard function: Dashboard creation	Create a dashboard with graph and measuring point data panels arranged.
Dashboard function: Dashboard creation: Available panel	Graph panel (created with graph function) Numeric panel (collected measuring point data) Image panel (image file)
Dashboard function: Display mode	Display the created dashboard on EcoAdviser.
Dashboard function: Display settings: Auto-update	Set the automatic update of graphs and measuring point data.
Dashboard function: Display settings: Tab display	Set the display of the tab for sheet switching.
Dashboard function: Display settings: Auto-switch	Set the automatic switching of the sheet at regular intervals.
Dashboard function: HTML output	Output the created dashboard to the HTML file.
Report function: Format	Set up the report format.
Report function: Format: Saving number of report settings	Max. 24 report settings (In one setting, output items of daily, monthly, and annual report are saved.)
Report function: Format: Number of output items	Daily report : Max. 320 items, 16 items per sheet × 20 sheets Monthly report : Max. 320 items, 16 items per sheet × 20 sheets Annual report : Max. 320 items, 16 items per sheet × 20 sheets
Report function: Format: Output item	Select from collection sources’ measuring points, manual input measuring points, product type time period measuring points, calculation measuring points, or specific consumption measuring points.
Report function: Report creation: Daily report	Create the daily report of a specified day and save it in the Excel format.
Report function: Report creation: Monthly report	Create the monthly report of a specified month and save it in the Excel format.
Report function: Report creation: Annual report	Create the annual report of a specified year and save it in the Excel format.
Report function: Automatic report output settings	Set the automatic output of reports.
Report function: Automatic report output settings: Automatic output time	Set the time of automatic output of reports.
Data collection function: File collection settings	Collect the logging files stored in the collection sources.
Data collection function: Collection source: EcoWebServerⅢ	Zoom (1 min.) data file, Demand (daily) data file
Data collection function: Collection source: Edgecross	Historical data file
Data collection function: Automatic collection settings	Set the data collection for each file type.
Data collection function: Automatic collection settings: Automatic collection timing	EcoWebServerⅢ : Collection time specified by the user Edgecross : Collection period specified by the user
Data collection function: Automatic collection settings: Collection period	Set the collection period on daily/monthly/annual basis.
Data collection function: Retention period	Set the retention period for each file type. 15/30/60-minute basis data: 2 to 10 years (Default: 10 years) Daily basis data: 2 to 10 years (Default: 10 years) Monthly basis data: 2 to 10 years (Default: 10 years) Annual basis data: 2 to 10 years (Default: 10 years)
Data input function: Data input	Input 15/30/60-minute basis data of each measuring point for a user-specified period. Max. 256 measuring points can be selected simultaneously. Specified period: Max. 31 days
Data input function: Export	Output 15-min/30-min/60-min/24-hour basis data of each measuring point for a user-specified period to the Excel file.
Data input function: Import	Input 15-min/30-min/60-min/24-hour basis data of each measuring point based on the imported Excel file.
Calculation function: Available measuring point	Select from product type time period measuring points, calculation measuring points, or specific consumption measuring points. * Max. 256 measuring points can be selected at one time.
Calculation function: Automatic calculation	Automatically calculate measuring point data.
Calculation function: Automatic calculation: Available measuring point	Select from product type time period measuring points, calculation measuring poins, or specific consumption measuring points.
Data output function: Data output	Output the collected measuring point data, which is saved in the file.
Data output function: Auto output settings for data file	Set the automatic output of data files.
Data output function: Auto output settings for data file: Output measuring point	Select from measuring points, manual input measuring points, product type time period measuring points, calculation measuring points, or specific consumption measuring points.
Maintenance function: Backup	Back up the setting values and data to the folder
Maintenance function: Restore	Restore the setting values and data backed up from the specified folder
PC’s Operation Environment: OS	Microsoft Windows 10 Pro/Enterprise/IoT Enterprise (64-bit) Microsoft Windows 11 Pro/Enterprise (64bit)
PC’s Operation Environment: Language version	Japanese, English, Simplified Chinese
PC’s Operation Environment: CPU	Intel Core TM i5-8500 or more (recommended)
PC’s Operation Environment: Memory	8GB or more
PC’s Operation Environment: Hard disk	Software: 4GB or more Data: 50GB or more *1
PC’s Operation Environment: LAN	10/100/1000BASE-T×1
PC’s Operation Environment: Spreadsheet *2	Microsoft Excel 2021 (64bit) Microsoft Excel 2024 (64bit)
PC’s Operation Environment: Display resolution	1024×768 pixels or more
PC’s Operation Environment: Input device	A mouse and keyboard

Downloads & documentation

Official documents from Mitsubishi Electric (Factory Automation), downloaded directly from the manufacturer.

Data sheets & manuals

Energy Saving Support Software EcoAdviser User's Manual (MODEL:MES3-EAP1-DA/MES3-EAP1-AI) (IB63E58-E)	PDF · 12.00MB
Energy Saving Support Software EcoAdviser User's Manual (MODEL:MES3-EAP1-DA/MES3-EAP1-AI) (IB63E59-E)	PDF · 9.31MB
File converter for EcoAdviser Userʼs Manual (IB63H21--)	PDF · 1.54MB
File converter for EcoAdviser (GEN64 Ver) Userʼs Manual (IB63H50-B)	PDF · 2.82MB
