Mitsubishi Electric CR860-R
Mitsubishi MELFA robot Controller
- MPN
- CR860-R
Request a Quote
- 1We check stock, condition and lead time
- 2You get a written quote by email
- 3Approve it and we ship — in-stock parts within 1 business day
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- 100% positive eBay feedback
- Ships via
Have spare Mitsubishi Electric (Factory Automation) parts? We buy surplus →
What is the Mitsubishi Electric CR860-R?
The Mitsubishi Electric CR860-R is a controller in the MELFA robot. MELSEC iQ-R series dedicaded. Specifications and manuals below are Mitsubishi Electric's own data.
Specifications
Product
| Series | MELFA robot |
| Outline | MELSEC iQ-R series dedicaded |
Specifications
| Category | Robot Controller |
| Series | CR860-R |
| Type | CR860-R |
| Applicable robot arm | RV-35FR/50FR/80FR-R |
| Robot CPU | R16RTCPU |
| Drive Unit | - |
| Path control method | - |
| Number of axes controlled | Maximum 6 axes + additional 8 axes availble |
| Robot language | MELFA-BASIC V, VI |
| Position teaching method | Teaching method, MDI method |
| Memory capacity: Number of teaching points: points | 39,000 |
| Memory capacity: Number of steps: step | 78,000 |
| Memory capacity: Number of programs: unit | 512 |
| External input/ output: General-purpose I/O: points | 0 input / 0 output (8192 input / 8192 output with the multiple CPU common device) |
| External input/ output: Dedicated I/O: points | Assigned to multiple CPU common divice |
| External input/ output: Special stop input: points | - |
| External input/ output: Gripper open/close: points | 12 input points / 8 output points |
| External input/ output: Emergency stop input: points | 1 (redundant) |
| External input/ output: Door switch input: points | 1 (redundant) |
| External input/ output: Enabling device input: points | 1 (redundant) |
| External input/ output: Mode selector switch input: points | - |
| External input/ output: Emergency stop output: points | 1 (redundant) |
| External input/ output: Mode output: points | 1 (redundant) |
| External input/ output: Robot error output: points | 1 (redundant) |
| External input/ output: Synchronization of additional axes: points | 1 (redundant) |
| External input/ output: Encoder input: channels | 2 |
| Interface: RS-232C: ports | - |
| Interface: RS-232: ports | - |
| Interface: RS-422: ports | 1 (Dedicated T/B) |
| Interface: Ethernet: ports | 1 (Dedicated T/B) 1 (1000BASE-T/100BASE-TX/10BASE-T) |
| Interface: USB: ports | - |
| Interface: Hand dedicated slot: slots | - |
| Interface: Key switch interface: points | - |
| Interface: Additional axis, force sensor interface: channels | 1 (SSCNET III/H) |
| Interface: Tracking interface: channels | - |
| Interface: Memory slot: slots | - |
| Interface: Extension slot: slots | - |
| Interface: Option slot: slots | 2 (Available only for function extension option card) |
| Interface: R/C communication interface: channels | - |
| Interface: Remote I/O: channels | 1 |
| Interface: Memory extension slot: slots | 1 (Unusable) |
| Interface: Ambient temperature: ˚C | 1 |
| Relative humidity: %RH | 0 to 45 (Controller) / 0 to 55(Robot CPU) |
| Power supply: Input voltage range: V | 10 to 85 |
| Power supply: Power capacity: KVA | Three-phase 200 to 240 (*1) |
| External dimensions (including legs): mm | 7.5 (*2) |
| Weight: kg | 670(W) × 500(D) × 670(H) |
| Structure [protective specification] | Approx. 80 |
| Grounding: Ω | Self-cotained floor type, Encolse type IP54 (FAN part : IP2X) |
| Control Type | 100Ω or less (Class D grounding) (*3) |
No matching specifications
Downloads & documentation
Official documents from Mitsubishi Electric (Factory Automation), downloaded directly from the manufacturer.
CR860-R: frequently asked questions
When can CR860-R be shipped?
CR860-R is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up CR860-R in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for CR860-R and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for CR860-R, subject to availability and destination.
