CW-15LMS Mitsubishi Power monitoring Current Transformers (CT)

MPN: CW-15LMS · Brand: Mitsubishi Electric (Factory Automation)

Price on request

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)

30-day returns, no restocking fee on unused parts

Ships via

Quick facts

Availability	Confirmed on request
Category	Mitsubishi Power monitoring – Instrument Transformers
Lifecycle	Active
Warranty	12-month (new) · 3-month (used/refurbished)

Shipping & availability

When can CW-15LMS be shipped?

CW-15LMS is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up CW-15LMS in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for CW-15LMS and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for CW-15LMS, subject to availability and destination.

The Mitsubishi Electric CW-15LMS is a current Transformers (CT) in the Power monitoring. Specifications and manuals below are Mitsubishi Electric's own data.

Specifications

Product

Series	Power monitoring
Category	Current Transformers (CT)
Type	Less than or equal to 1100V

Specifications

Category	Instrument Transformers
Group	Current Transformers (CT)
Circuit voltage	Less than or equal to 1100V
Use	General-use meters
Model name	CW-15LMS
Rated primary current (A)	200
Secondary current (A)	5
Rated burden (VA)	15
Applicable standards	JIS C 1731-1
Accuracy (class)	1.0
Overcurrent strength (times)	40
Highest voltage / withstand voltage (kV)	1.15/4/－
Frequency (Hz)	50 or 60
Square window dimensions (mm)	14×55
Mass (kg)	1.1
