Mitsubishi Electric CR860-Q

Mitsubishi MELFA robot Controller

MPN
CR860-Q
Price and lead time confirmed within 1 business day
Request a Quote
  1. 1We check stock, condition and lead time
  2. 2You get a written quote by email
  3. 3Approve it and we ship — in-stock parts within 1 business day

A real person replies, typically within 1 business day — see our privacy policy.

  • 12-month warranty (new) · 3-month (used/refurbished)
  • 30-day returns, no restocking fee on unused parts
  • 100% positive eBay feedback
  • Ships via

Have spare Mitsubishi Electric (Factory Automation) parts? We buy surplus →

What is the Mitsubishi Electric CR860-Q?

The Mitsubishi Electric CR860-Q is a controller in the MELFA robot. MELSEC Q series dedicaded. Specifications and manuals below are Mitsubishi Electric's own data.

Specifications

Product

SeriesMELFA robot
OutlineMELSEC Q series dedicaded

Specifications

CategoryRobot Controller
SeriesCR860-Q
TypeCR860-Q
Applicable robot armRV-35FR/50FR/80FR-Q
Robot CPUQ172DSRCPU
Drive Unit-
Path control method-
Number of axes controlledMaximum 6 axes + additional 8 axes availble
Robot languageMELFA-BASIC V, VI
Position teaching methodTeaching method, MDI method
Memory capacity: Number of teaching points: points26,000
Memory capacity: Number of steps: step52,000
Memory capacity: Number of programs: unit512
External input/ output: General-purpose I/O: points0 input / 0 output (8192 input / 8192 output with the multiple CPU common device)
External input/ output: Dedicated I/O: pointsAssigned to multiple CPU common divice
External input/ output: Special stop input: points-
External input/ output: Gripper open/close: points12 input points / 8 output points
External input/ output: Emergency stop input: points1 (redundant)
External input/ output: Door switch input: points1 (redundant)
External input/ output: Enabling device input: points1 (redundant)
External input/ output: Mode selector switch input: points-
External input/ output: Emergency stop output: points1 (redundant)
External input/ output: Mode output: points1 (redundant)
External input/ output: Robot error output: points1 (redundant)
External input/ output: Synchronization of additional axes: points1 (redundant)
External input/ output: Encoder input: channelsQ173DPX (optional)
Interface: RS-232C: ports-
Interface: RS-232: ports-
Interface: RS-422: ports1 (Dedicated T/B)
Interface: Ethernet: ports1 (Dedicated T/B) 1 (1000BASE-T/100BASE-TX/10BASE-T)
Interface: USB: ports-
Interface: Hand dedicated slot: slots-
Interface: Key switch interface: points-
Interface: Additional axis, force sensor interface: channels1 (SSCNET III/H)
Interface: Tracking interface: channels-
Interface: Memory slot: slots-
Interface: Extension slot: slots-
Interface: Option slot: slots2 (Available only for function extension option card)
Interface: R/C communication interface: channels-
Interface: Remote I/O: channels1
Interface: Memory extension slot: slots1 (Unusable)
Interface: Ambient temperature: ˚C1
Relative humidity: %RH0 to 45 (Controller) / 0 to 55(Robot CPU)
Power supply: Input voltage range: V10 to 85
Power supply: Power capacity: KVAThree-phase 200 to 240 (*1)
External dimensions (including legs): mm7.5 (*2)
Weight: kg670(W) × 500(D) × 670(H)
Structure [protective specification]Approx. 80
Grounding: ΩSelf-cotained floor type, Encolse type IP54 (FAN part : IP2X)
Control Type100Ω or less (Class D grounding) (*3)

Downloads & documentation

Official documents from Mitsubishi Electric (Factory Automation), downloaded directly from the manufacturer.

Data sheets & manuals

CR860-Q: frequently asked questions

When can CR860-Q be shipped?

CR860-Q is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up CR860-Q in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for CR860-Q and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for CR860-Q, subject to availability and destination.
