Danfoss 24241-10-10H16ZF

HOSE NIPPLE ASSY,2P/10,ORS-F/10,CS,45D

MPN
24241-10-10H16ZF
Price and lead time confirmed within 1 business day
Request a Quote
  1. 1We check stock, condition and lead time
  2. 2You get a written quote by email
  3. 3Approve it and we ship — in-stock parts within 1 business day

A real person replies, typically within 1 business day — see our privacy policy.

  • 12-month warranty (new) · 3-month (used/refurbished)
  • 30-day returns, no restocking fee on unused parts
  • 100% positive eBay feedback
  • Ships via

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 24241-10-10H16ZF?

Danfoss HOSE NIPPLE ASSY,2P/10,ORS-F/10,CS,45D, manufacturer part number 24241-10-10H16ZF. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

Specifications

EAN/UPC678146192011
A dimension IN3.410
A dimension MM86.600
Angle shape45 Degree
Compatible hose ID IN0.620
Compatible hose ID MM15.875
Compatible hoses EC110, EC115, EC210, EC215
Construction StyleCrimp
Drop dimension IN0.630
Drop dimension MM16.00
End size 1-10
End Type 1Female ORFS swivel
Finish platingZinc plating
Hex size 1 IN1.188
Hex size 1 MM30.000
Hose cut off factor IN2.070
Hose cut off factor MM52.600
Hose size-10
Inside diameter IN0.470
Inside diameter MM11.900
Product height in1.571
Product height mm39.901
Product length in4.457
Product length mm113.200
Product materialCarbon steel
Product width in1.181
Product width mm30
Thread sealantNo
Thread size 11-14 UNS
Working pressure max BAR552
Working pressure max PSI8100

24241-10-10H16ZF: frequently asked questions

When can 24241-10-10H16ZF be shipped?

24241-10-10H16ZF is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 24241-10-10H16ZF in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 24241-10-10H16ZF and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 24241-10-10H16ZF, subject to availability and destination.
