Danfoss 20291-18-05TZ
HOSE NIPPLE, 2P/05, MORFS-F/18, CS, 90D
- MPN
- 20291-18-05TZ
- Category
- Braided hose and fittings
Price and lead time confirmed within 1 business day
Request a Quote
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- Ships via
- 100% positive eBay feedback
What is the Danfoss 20291-18-05TZ?
Danfoss HOSE NIPPLE, 2P/05, MORFS-F/18, CS, 90D, manufacturer part number 20291-18-05TZ. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.
Specifications
Specifications
| A dimension IN | 2.401 |
| A dimension MM | 61.000 |
| Angle shape | 90 Degree |
| Brand | Winner by Danfoss |
| Compatible hose ID IN | 0.310 |
| Compatible hose ID MM | 7.900 |
| Construction Style | Crimp |
| Drop dimension IN | 1.456 |
| Drop dimension MM | 37.00 |
| Finish plating | Zinc plating |
| Hose cut off factor IN | 1.299 |
| Hose cut off factor MM | 33.000 |
| Hose size | -5 |
| Inside diameter IN | 0.216 |
| Inside diameter MM | 5.500 |
| Product height in | 1.732 |
| Product height mm | 44.000 |
| Product length in | 2.710 |
| Product length mm | 68.830 |
| Product material | Carbon steel |
| Product width in | 0.945 |
| Product width mm | 24 |
| Series | Winner 2-Piece |
| Thread size 1 | M18x1.5 |
| Working temperature max C | 100 |
| Working temperature max F | 212 |
| Working temperature min C | -40 |
| Working temperature min F | -40 |
20291-18-05TZ: frequently asked questions
When can 20291-18-05TZ be shipped?
20291-18-05TZ is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up 20291-18-05TZ in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for 20291-18-05TZ and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 20291-18-05TZ, subject to availability and destination.
