Danfoss 1A10DK6

HOSE FTG, 1A/06, DKL-M/10, CS, STR

MPN: 1A10DK6
Category: Braided hose and fittings

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 1A10DK6?

Danfoss HOSE FTG, 1A/06, DKL-M/10, CS, STR, manufacturer part number 1A10DK6. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

EAN/UPC	678146123237
A dimension IN	1.930
A dimension MM	49.000
Angle shape	Straight
Brand	Aeroquip by Danfoss
Compatible hose ID IN	0.380
Compatible hose ID MM	9.500
Compatible tube OD IN	0.63
Compatible tube OD MM	15.875
Construction Style	Crimp
End size 1	-10
End Type 1	24 deg. tube port light duty
Finish plating	Dura-Kote
Hex size 1 IN	0.000
Hex size 1 MM	0.000
Hex size 2 IN	0.750
Hex size 2 MM	19.000
Hose cut off factor IN	0.930
Hose cut off factor MM	23.700
Hose size	-6
Inside diameter IN	0.260
Inside diameter MM	6.700
Product height in	1.070
Product height mm	27.178
Product length in	1.930
Product length mm	49.022
Product material	Carbon steel
Product width in	1.070
Product width mm	27.178
Proposition 65	Cancer and Reproductive Harm
Series	1A/Z Series
Thread sealant	No
Thread size 1	M18x1.5
Tube OD 1 IN	0.625
Tube OD 1 MM	15.875
Working pressure max BAR	160.00
Working pressure max PSI	2300.00
Working temperature max C	150
Working temperature max F	302
Working temperature min C	-40
Working temperature min F	-40

1A10DK6: frequently asked questions

When can 1A10DK6 be shipped?

1A10DK6 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 1A10DK6 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 1A10DK6 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 1A10DK6, subject to availability and destination.
