Danfoss 1A10DK5

HOSE FTG, 1A/05, DKL-M/10, CS, STR

MPN: 1A10DK5
Category: Braided hose and fittings

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via
100% positive eBay feedback

Have spare Danfoss (Drives) parts? We buy surplus →

What is the Danfoss 1A10DK5?

Danfoss HOSE FTG, 1A/05, DKL-M/10, CS, STR, manufacturer part number 1A10DK5. Sourced on request from PartnerPLC — contact us to check availability, condition and lead time.

Specifications

A dimension IN	1.840
A dimension MM	46.800
Angle shape	Straight
Brand	Aeroquip by Danfoss
Compatible hose ID IN	0.310
Compatible hose ID MM	7.900
Construction Style	Crimp
End size 1	-10
End Type 1	24 deg. tube port light duty
Finish plating	Dura-Kote
Hex size 1 IN	0.748
Hex size 1 MM	19.000
Hex size 2 MM	19.000
Hose cut off factor IN	0.900
Hose cut off factor MM	22.900
Hose size	-5
Inside diameter IN	0.210
Inside diameter MM	5.300
Product height in	0.969
Product height mm	24.600
Product length in	1.843
Product length mm	46.800
Product material	Carbon steel
Product width in	0.969
Product width mm	24.6
Proposition 65	Cancer and Reproductive Harm
Series	1A/Z Series
Thread sealant	No
Thread size 1	M18x1.5
Working pressure max BAR	160.00
Working pressure max PSI	2300.00
Working temperature max C	150
Working temperature max F	302
Working temperature min C	-40
Working temperature min F	-40

1A10DK5: frequently asked questions

When can 1A10DK5 be shipped?

1A10DK5 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.

Can I pick up 1A10DK5 in person?

Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.

Is express delivery available?

Yes — mention it when you request a quote for 1A10DK5 and we'll include express shipping options in our reply.

My factory is down and I need this urgently — can you help?

For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 1A10DK5, subject to availability and destination.
