B&R 5AP951.1505-01
Request a Quote
Quick facts
| Availability | Confirmed on request |
| Lifecycle | active |
| Warranty | 12-month (new) · 3-month (used/refurbished) |
| Weight | 0.59 kg |
Shipping & availability
When can 5AP951.1505-01 be shipped?
5AP951.1505-01 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up 5AP951.1505-01 in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for 5AP951.1505-01 and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 5AP951.1505-01, subject to availability and destination.
15" XGA color TFT displayFunction keys, system keys and soft keysSmall installation depthFan-free operationCan be upgraded with Display Link cards or PPC300 Automation Panel AP951, 15" XGA color TFT display, 12 soft keys, 20 function keys and 92 system keys, 3 USB 2.0 interfaces, slot for Automation Panel Link, IP65 protection (front). 24 VDC.
Specifications
Specifications
| B&R ID code | 0x1D5F |
| CE | Yes |
| UKCA | Yes |
| Type | USB 2.0 |
| Diagonal | 15" (381 mm) |
| Colors | 16.7 million |
| Resolution | XGA, 1024 x 768 pixels |
| Contrast | 400:1 |
| Horizontal | Direction R = 85° / Direction L = 85° |
| Vertical | Direction U = 85° / Direction D = 85° |
| Brightness | 250 cd/m² |
| Half-brightness time | 50,000 h |
| Transmittance | - |
| Anti-glare coating | On both sides |
| Technology | - |
| Controller | - |
| Quantity | 3 |
| Variant | Type A |
| Transfer rate | Low speed (1.5 Mbit/s), full speed (12 Mbit/s) to high speed (480 Mbit/s) |
| Current-carrying capacity | Max. 500 mA per connection |
| Function keys | 20 with LED (yellow) |
| Soft keys | 12 with LED (yellow) |
| System keys | Alphanumeric keys, numeric keys, cursor block |
| Service life | >1,000,000 actuations at 1 ±0.3 N to 3 ±0.3 N actuating force |
| Yellow | Typ. 12 mcd |
| Compatible installation for PPC300 slot | No |
| Nominal voltage | 24 VDC ±25%, SELV |
| Nominal current | Max. 3.2 A |
| Inrush current | Typ. 6 A, max. 30 A for < 300 µs |
| Power consumption | Typ. 24 W (without LED), max. 32 W or 42 W with USB (without slot) |
| Galvanic isolation | Yes |
| Pollution degree per EN 61131-2 | Pollution degree 2 |
| Degree of protection per EN 60529 | Back: IP20 (only with an inserted Automation Panel Link card) Front: IP65 / NEMA 250 type 4X indoor, protected against dust and hose-directed water |
| Operation | Max. 3000 m |
| Storage | 30 g, 15 ms |
| Transport | 30 g, 15 ms |
| Operation (continuous) | 2 to 9 Hz: 1.75 mm amplitude / 9 to 200 Hz: 0.5 g |
| Operation (occasional) | 2 to 9 Hz: 3.5 mm amplitude / 9 to 200 Hz: 1 g |
| Material | Polyester |
| Coating | Similar to Pantone 432CV |
| Frame | Aluminum, naturally anodized |
| Design | Gray |
| Light background color | Similar to Pantone 427CV |
| Dark border color around display | Similar to Pantone 432CV |
| Dark gray keys color | Similar to Pantone 431CV |
| Orange keys color | Similar to Pantone 151CV |
| Color slide-in labels | Similar to Pantone 429CV |
| Gasket | Flat gasket around display front |
| Width | 435 mm |
| Height | 430 mm |
| Depth | 54 mm |
| Weight | Approx. 5900 g |
