B&R 5ACPCI.RAIC-02
This hard disk can be as a replacement for a HDD …
- MPN
- 5ACPCI.RAIC-02
Price and lead time confirmed within 1 business day
Request a Quote
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- Ships via
What is the B&R 5ACPCI.RAIC-02?
This hard disk can be used as a replacement for a HDD used with the 5ACPCI.RAIC-01 PCI SATA RAID controller.
Specifications
General information
| Certifications – CE | Yes |
| Certifications – UKCA | Yes |
| Certifications – UL | cULus E115267; Industrial control equipment |
| Certifications – HazLoc | cULus HazLoc E180196; Industrial control equipment; for hazardous locations; Class I, Division 2, Groups ABCD (note: Yes, but applies only if all components installed in the complete system have this certification and the complete system bears the corresponding mark.) |
Hard disk
| Data transfer rate – Internal | Max. 539 Mbit/s |
| Data transfer rate – To/From host | Max. 150 MB/s |
| Positioning time – Minimum (track to track) | 1.5 ms |
| Positioning time – Nominal (read access) | 10.5 ms |
| Positioning time – Maximum (read access) | 22 ms |
| Capacity | 60 GB |
| Number of heads | 3 |
| Number of sectors | 117,210,240 |
| Bytes per sector | 512 |
| Cache | 8 MB |
| Speed | 7200 rpm ±1% |
| Startup time | Typ. 4 s (from 0 rpm to read access) |
| Service life | 5 years |
| S.M.A.R.T. support | Yes |
| Access time | 4.2 ms |
| Supported transfer modes | SATA 1.0, PIO mode 0-4, multiword DMA mode 0-2, UDMA 0-5 |
Ambient conditions
| Temperature – Operation | 5 to 55°C (note: Temperature specifications at 305 meters above sea level. The temperature specification must be reduced linearly by 1°C every 305 meters. The temperature is permitted to increase or decrease by a maximum of 3°C per minute.) |
| Temperature – 24-hour operation | 5 to 40°C (note: Temperature specifications at 305 meters above sea level. The temperature specification must be reduced linearly by 1°C every 305 meters. The temperature is permitted to increase or decrease by a maximum of 3°C per minute.) |
| Temperature – Storage | -40 to 70°C (note: Temperature specifications at 305 meters above sea level. The temperature specification must be reduced linearly by 1°C every 305 meters. The temperature is permitted to increase or decrease by a maximum of 3°C per minute.) |
| Temperature – Transport | -40 to 70°C (note: Temperature specifications at 305 meters above sea level. The temperature specification must be reduced linearly by 1°C every 305 meters. The temperature is permitted to increase or decrease by a maximum of 3°C per minute.) |
| Relative humidity – Operation | 5 to 90%, non-condensing |
| Relative humidity – Storage | 5 to 95%, non-condensing |
| Relative humidity – Transport | 5 to 95%, non-condensing |
| Vibration – Operation (continuous) | 5 to 500 Hz: 0.125 g (1.225 m/s² 0-peak) duration 1 octave per minute, no damage (note: Operation in areas prone to vibration and shock can affect performance negatively (reduction of transfer rate).) |
| Vibration – Operation (occasional) | 5 to 500 Hz: 0.25 g (2.45 m/s² 0-peak) duration 1 octave per minute, no damage (note: Operation in areas prone to vibration and shock can affect performance negatively (reduction of transfer rate).) |
| Vibration – Storage | At max. 5 to 500 Hz: 5 g (49 m/s² 0-peak) duration 0.5 octaves per minute, no damage (note: Operation in areas prone to vibration and shock can affect performance negatively (reduction of transfer rate).) |
| Vibration – Transport | At max. 5 to 500 Hz: 5 g (49 m/s² 0-peak) duration 0.5 octaves per minute, no damage (note: Operation in areas prone to vibration and shock can affect performance negatively (reduction of transfer rate).) |
| Shock – Operation | At max. 125 g (1226 m/s² 0-peak) and 2 ms duration: No unrecoverable errors |
| Shock – Storage | At max. 400 g (3924 m/s² 0-peak) and 2 ms duration, no damage ; At max. 450 g (4424 m/s² 0-peak) and 1 ms duration, no damage ; At max. 200 g (1962 m/s² 0-peak) and 0.5 ms duration, no damage |
| Shock – Transport | At max. 400 g (3924 m/s² 0-peak) and 2 ms duration, no damage ; At max. 450 g (4424 m/s² 0-peak) and 1 ms duration, no damage ; At max. 200 g (1962 m/s² 0-peak) and 0.5 ms duration, no damage |
| Elevation – Operation | -300 to 3048 m |
| Elevation – Storage | -300 to 12192 m |
Mechanical properties
| Dimensions – Width | 70 mm |
| Dimensions – Length | 100 mm |
| Dimensions – Height | 9.5 mm |
| Weight | 350 g |
Vendor information
| Manufacturer | Seagate |
| Manufacturer's product ID | Momentus 7200.1 ST96023AS |
