WORKPIECE PALLET WT 2/F
Request a Quote
Quick facts
| Availability | Confirmed on request |
| Category | Workpiece pallet WT 2/F |
| Lifecycle | active |
| Warranty | 12-month (new) · 3-month (used/refurbished) |
Shipping & availability
When can 3842999941 be shipped?
3842999941 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up 3842999941 in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for 3842999941 and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 3842999941, subject to availability and destination.
WT 2/F workpiece pallets Frame workpiece pallet, fully assembled or as a kit for self-assembly Low weight and high stability thanks to the aluminum frame construction Especially suitable for low-cost transportation of large products Continuous standard grooves to easily fasten cross struts and workpiece supports Integrated positioning bushings Various wear pads for use on all conveyor media PA wear pads (LS = 0) for use on belts, toothed belts, or flat top chains PE wear pads (LS = 1) for use on accumulation roller chains
Specifications
Specifications
| Workpiece pallet total weight [mG] [kg] | 100 |
| Workpiece pallet length [lWT] [mm] | 1040; 400; 480; 640; 800 |
| Kit [MT] | 0 = unmontiert; 1 = montiert |
| Scope of delivery | Connection elements; Frame modules; Positioning bushings |
| Delivery information | Kit, not mounted (MT = 0); Mounted (MT = 1) |
| Workpiece pallet width [bWT] [mm] | 400; 480; 640; 800 |
| Weight [kg] | 0 |
