Beckhoff KL8548

8-channel analog output module 0…10 V

MPN: KL8548
Category: KL85xx | Manual operating

Price and lead time confirmed within 1 business day

Request a Quote

12-month warranty (new) · 3-month (used/refurbished)
30-day returns, no restocking fee on unused parts
Ships via

What is the Beckhoff KL8548?

The KL8548 is an 8-channel analog output module for 0 to 10 V. The analog values must be specified individually for each channel via the controller or via a potentiometer. The actual output value is indicated by a bar graph. The position of the

Specifications

Number of inputs	8 (potentiometer)
Number of outputs	8 (0…10 V)
Signal voltage	0…10 V
Resolution	12 bit
Nominal voltage	24 V DC (-15%/+20%)
Current consumption K-bus	50 mA in ECO mode, 95 mA in full scale mode
Power supply	24 V connection
Bus interface	K-bus connection IN/OUT
I/O connection	flat-ribbon cable connection, 20-pin, shielded
Switch settings	auto/manual, potentiometer
Diagnostics LED	yellow
Special features	Potentiometers and switches can be read via the PLC. Analog values are displayed in the form of bar charts.
Weight	approx. 215 g
Operating temperature	0…55°C
Storage temperature	-25…+85°C
Relative humidity	95%, no condensation
Vibration/shock resistance	conforms to EN 60068-2-6/EN 60068-2-27
EMC immunity/emission	conforms to EN 61000-6-2/EN 61000-6-4
Protect. rating/installation pos.	IP20/variable
Approvals/markings	CE
