ABB 1SFN014328R1001
CCL18-01 Auxiliary Contact Block
- MPN
- 1SFN014328R1001
- EAN
- 7320500256336
- Category
- ABB Block Contactors
Request a Quote
- 1We check stock, condition and lead time
- 2You get a written quote by email
- 3Approve it and we ship — in-stock parts within 1 business day
- 12-month warranty (new) · 3-month (used/refurbished)
- 30-day returns, no restocking fee on unused parts
- 100% positive eBay feedback
- Ships via
What is the ABB 1SFN014328R1001?
CCL18-01 Auxiliary Contact Block
Specifications
General
| Order code (ABB product ID) | 1SFN014328R1001 |
| Type | AUX. CONTACT CCL18-01 |
| Lifecycle | Active (current ABB product) |
Ordering
| Minimum Order Quantity | 1 piece |
| Customs Tariff Number | 85369010 |
Dimensions
| Product Net Width | 65 mm |
| Product Net Depth / Length | 15 mm |
| Product Net Height | 70 mm |
| Product Net Weight | 0.04 kg |
Technical
| Rated Operational Voltage | Auxiliary Circuit 24 ... 690 V |
| Power Loss | at Rated Operating Conditions per Pole 0.15 W |
| Connecting Capacity Auxiliary Circuit | Flexible with Ferrule 1x 0.75 ... 2.5 mm², Flexible with Ferrule 2x 0.75 ... 2.5 mm², Flexible with Insulated Ferrule 1x 0.75 ... 2.5 mm², Flexible with Insulated Ferrule 2x 0.75 ... 2.5 mm², Solid 1x 1 ... 4 mm², Solid 2x 1 ... 4 mm² |
| Wire Stripping Length | Auxiliary Circuit 9 mm |
| Recommended Screw Driver | Auxiliary Circuit 1 x 5.5, Auxiliary Circuit Pozidriv 2 |
| Tightening Torque | Auxiliary Circuit 1 N·m |
| Terminal Type | Screw Terminals |
| Suitable For | AF400, AF460, AF580, AF750, AF1250, AF1250H, AF1350, AF1650, AF2050, AF2650, AF1350T, AF1650T, AF2050T, AF2650T, GAF185, GAF300, GAF460, GAF750, GAF1250, GAF2050, A95, A110, A145, A185, A210, A260, A300, A130, A320, UA95, UA110, UAF95, UAF110, AF95, AF110, AF145, AF185, AF210, AF260, AF300 |
| Product Name | Auxiliary Contact Block |
Material Compliance
| WEEE B2C / B2B | Business To Business |
| WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
External Classifications and Standards
| Object Classification Code | K |
| ETIM 7 | EC000041 - Auxiliary contact block |
| ETIM 8 | EC000041 - Auxiliary contact block |
| ETIM 9 | EC000041 - Auxiliary contact block |
| eClass | V11.0 : 27371302 |
| UNSPSC | 39121529 |
No matching specifications
Downloads & documentation
Official documents from ABB, downloaded directly from the manufacturer.
Data sheets & manuals
CAD & dimension drawings
1SFN014328R1001: frequently asked questions
When can 1SFN014328R1001 be shipped?
1SFN014328R1001 is sourced on request — request a quote and we'll confirm the exact availability and shipping timeline for this specific unit.
Can I pick up 1SFN014328R1001 in person?
Local pickup from our Groningen, Netherlands warehouse may be possible — contact us before ordering to check availability and arrange a collection time.
Is express delivery available?
Yes — mention it when you request a quote for 1SFN014328R1001 and we'll include express shipping options in our reply.
My factory is down and I need this urgently — can you help?
For a critical breakdown, contact us directly at +31 (0)50-7110348 or sales@partnerplc.com — we can look into same-day courier or dedicated taxi/hotshot delivery for 1SFN014328R1001, subject to availability and destination.
