3VA Molded Case Circuit Breakers up to 2000 A, UL / IEC Parts
Compare 3VA Molded Case Circuit Breakers up to 2000 A, UL / IEC
Key specifications of the parts listed on this page, taken from the manufacturer's data sheets.
| MPN | product designation / according to UL file | power loss [W] / maximum | power loss [W] / for rated value of the current / at AC / in hot operating state / per pole | Net Weight | adjustable response value setting current (Ii) / for I-tripping — minimum |
|---|---|---|---|---|---|
| 3VA6115-8JT41-0AA0 | LDAE | 29 W | 9.67 W | 3.2 kg | 225 A |
| 3VA5112-1MU31-0AA0 | HEAP | 30 W | 10 W | 955 g | 375 A |
| 3VA5112-1MH31-0AA0 | HEAP | 30 W | 10 W | 947 g | 625 A |
| 3VA5111-6ED41-0AA0 | HEAS | 25.8 W | 8.6 W | 1.18 g | 1 100 A |
| 3VA5135-6ED21-1AA0 | HEAM | 7.6 W | 3.8 W | 621 g | 350 A |
| 3VA5135-6ED21-0AA0 | HEAS | 7.6 W | 3.8 W | 621 g | 350 A |
| 3VA5135-6EC31-1AA0 | HEAM | 11.4 W | 3.8 W | 950 g | 175 A |
| 3VA5135-6EC31-0AA0 | HEAS | 11.4 W | 3.8 W | 942 g | 175 A |
| 3VA5135-5ED11-0AA0 | MEAS | 3.8 W | 3.8 W | 0.383 kg | 350 A |
| 3VA5135-5EC41-0AA0 | MEAS | 11.4 W | 3.8 W | 952 g | 175 A |
| 3VA5135-5EC31-0AA0 | MEAS | 11.4 W | 3.8 W | 944 g | 175 A |
| 3VA5135-4ED41-0AA0 | SEAS | 11.4 W | 3.8 W | 1.165 kg | 350 A |
| 3VA5180-4ED31-0AA0 | SEAS | 19.3 W | 6.43 W | 940 g | 800 A |
| 3VA5320-5EC31-1AA0 | MJAM | 38 W | 12.5 W | 5.2 kg | 1 250 A |
| 3VA5295-7ED36-0AA0 | CFAS | 5.1 W | 1.7 W | 2 100 g | 400 A |
| 3VA5295-7ED32-1AA0 | CFAM | 5.1 W | 1.7 W | 2 100 g | — |
| 3VA6210-6KT41-2AA0 | HFAE | 6.7 W | 2.23 W | 2.9 kg | 150 A |
| 3VA6610-6KL32-0AA0 | HMNAE | 330 W | 110 W | 14.1 kg | 1 500 A |
| 3VA6610-5KT42-0AA0 | MMNAE | 330 W | 110 W | 17.02 kg | 1 500 A |
| 3VA6610-5KT36-0AA0 | MMNAE | 330 W | 110 W | 17.755 kg | 1 500 A |
| 3VA6610-5KT32-0AA0 | MMNAE | 330 W | 110 W | 13.362 kg | 1 500 A |
| 3VA6610-5KQ46-0AA0 | MMNAE | 330 W | 110 W | 23.298 kg | 1 500 A |
| 3VA6610-5KQ42-0AA0 | MMNAE | 330 W | 110 W | 17.02 kg | 1 500 A |
| 3VA6610-5KQ36-0AA0 | MMNAE | 330 W | 110 W | 17.755 kg | 1 500 A |
Common to all listed parts
| product designation | Molded-case circuit breaker |
| design of the load switch / according to UL 489 / Heating, Air Conditioning, and Refrigeration circuit breaker (HACR Type) | Yes |
| number of CO contacts / for auxiliary contacts | 0 |
| protection class IP / on the front | IP40 |
| reference code / according to IEC 81346-2 | Q |
